企业运维之 kubernetes(k8s) 的存储

一、Configmap配置管理

二、Secret配置管理

三、Volumes配置管理

四、kubernetes调度

五、kubernetes访问控制

一、Configmap配置管理

Configmap用于保存配置数据，以键值对形式存储；

ConfigMap资源提供了向Pod注入配置数据的方法，旨在让镜像和配置文件解耦，以便实现镜像的可移植性和可复用性；

典型的使用场景有：填充环境变量的值、设置容器内的命令行参数、填充卷的配置文件

1.创建ConfigMap的方式有4种：使用字面值创建、使用文件创建、使用目录创建、编写configmap的yaml文件创建


##使用字面值创建，键值对的方式：
[root@node22 ~]# mkdir configmap
[root@node22 ~]# cd configmap/
[root@node22 configmap]# ls
[root@node22 configmap]# kubectl create configmap my-config --from-literal=key1=config1 --from-literal=key2=config2
configmap/my-config created
[root@node22 configmap]# kubectl get cm
NAME               DATA   AGE
kube-root-ca.crt   1      3d5h
my-config          2      8s
[root@node22 configmap]# kubectl describe cm my-config
Name:         my-config
Namespace:    default
Labels:       <none>
Annotations:  <none>

Data
====
key2:
----
config2
key1:
----
config1

BinaryData
====

Events:  <none>

##使用文件创建，文件名为key，文件内容为值
[root@node22 configmap]# kubectl create configmap my-config-2 --from-file=/etc/resolv.conf
configmap/my-config-2 created
[root@node22 configmap]# kubectl describe cm my-config-2
Name:         my-config-2
Namespace:    default
Labels:       <none>
Annotations:  <none>

Data
====
resolv.conf:
----
# Generated by NetworkManager
nameserver 114.114.114.114


BinaryData
====

Events:  <none>

##使用目录创建，文件名为key，文件内容为值
[root@node22 configmap]# kubectl create configmap my-config-3 --from-file=test
configmap/my-config-3 created
[root@node22 configmap]# kubectl describe cm my-config-3
Name:         my-config-3
Namespace:    default
Labels:       <none>
Annotations:  <none>

Data
====
passwd:
----
root:x:0:0:root:/root:/bin/bash
bin:x:1:1:bin:/bin:/sbin/nologin
daemon:x:2:2:daemon:/sbin:/sbin/nologin
adm:x:3:4:adm:/var/adm:/sbin/nologin
lp:x:4:7:lp:/var/spool/lpd:/sbin/nologin
sync:x:5:0:sync:/sbin:/bin/sync
shutdown:x:6:0:shutdown:/sbin:/sbin/shutdown
fstab:
----

#
# /etc/fstab
# Created by anaconda on Fri Aug  5 17:48:43 2022
#
# Accessible filesystems, by reference, are maintained under '/dev/disk'
# See man pages fstab(5), findfs(8), mount(8) and/or blkid(8) for more info
#
/dev/mapper/rhel-root   /                       xfs     defaults        0 0
UUID=d319ed7a-9c18-4cda-b34a-9e2399f1f1fc /boot                   xfs     defaults        0 0
#/dev/mapper/rhel-swap   swap                    swap    defaults        0 0


BinaryData
====

Events:  <none>

##编写comfigmap的yml文件创建
[root@node22 configmap]# vim cm1.yaml
apiVersion: v1
kind: ConfigMap
metadata:
 name: cm1-config
data:
 db_host: "192.168.0.1"
 db_port: "3306"
[root@node22 configmap]# kubectl apply -f cm1.yaml
configmap/cm1-config created
[root@node22 configmap]# kubectl get cm
NAME               DATA   AGE
cm1-config         2      11s
kube-root-ca.crt   1      3d5h
my-config          2      9m45s
my-config-2        1      5m54s
my-config-3        2      3m23s
[root@node22 configmap]# kubectl describe cm cm1-config
Name:         cm1-config
Namespace:    default
Labels:       <none>
Annotations:  <none>

Data
====
db_port:
----
3306
db_host:
----
192.168.0.1

BinaryData
====

Events:  <none>

2.如何使用configmap：


1).通过环境变量的方式直接传递给pod
[root@node22 configmap]# vim pod.yaml
apiVersion: v1
kind: Pod
metadata:
  name: pod1
spec:
  containers:
    - name: pod1
      image: busybox
      command: ["/bin/sh", "-c", "env"]
      env:
        - name: key1
          valueFrom:
            configMapKeyRef:
              name: cm1-config
              key: db_host
        - name: key2
          valueFrom:
            configMapKeyRef:
              name: cm1-config
              key: db_port
  restartPolicy: Never
[root@node22 configmap]# kubectl apply -f pod.yaml
pod/pod1 created
[root@node22 configmap]# kubectl get pod
NAME                       READY   STATUS      RESTARTS      AGE
demo                       1/1     Running     1 (32m ago)   32m
myapp-1-6666f57846-n8zgn   1/1     Running     0             87m
pod1                       0/1     Completed   0             101s
[root@node22 configmap]# kubectl delete pod pod1
pod "pod1" deleted
[root@node22 configmap]# kubectl delete pod demo --force
[root@node22 configmap]# kubectl delete deployments.apps myapp-1
[root@node22 configmap]# kubectl -n test delete pod demo --force

2)	.通过在pod的命令行下运行的方式
##使用conigmap设置命令行参数
[root@node22 configmap]# vim pod2.yaml
apiVersion: v1
kind: Pod
metadata:
  name: pod1
spec:
  containers:
    - name: pod1
      image: busybox
      command: ["/bin/sh", "-c", "echo $(db_host) $(db_port)"]
      envFrom:
        - configMapRef:
            name: cm1-config
  restartPolicy: Never
[root@node22 configmap]# kubectl apply -f pod2.yaml
pod/pod1 created

3).作为volume的方式挂载到pod内
##通过数据卷使用configmap
[root@node22 configmap]# vim pod3.yaml
kind: Pod
metadata:
  name: pod2
spec:
  containers:
    - name: pod2
      image: busybox
      command: ["/bin/sh", "-c", "cat /config/db_host"]
      volumeMounts:
      - name: config-volume
        mountPath: /config
  volumes:
    - name: config-volume
      configMap:
        name: cm1-config
  restartPolicy: Never
[root@node22 configmap]# kubectl apply -f pod3.yaml
pod/pod2 created
[root@node22 configmap]# kubectl get pod
NAME   READY   STATUS      RESTARTS   AGE
pod2   0/1     Completed   0          57s
[root@node22 configmap]# kubectl logs pod2
192.168.0.1

示例：

例子：configmap热更新

[root@node22 configmap]# vim nginx.conf

server {

    listen 8000;

    server_name _;

    location / {

        root /usr/share/nginx/html;

        index index.html index.htm;

    }

}

[root@node22 configmap]# kubectl create configmap nginxconf --from-file=nginx.conf

configmap/nginxconf created

[root@node22 configmap]# kubectl get cm

NAME               DATA   AGE

cm1-config         2      28m

kube-root-ca.crt   1      3d6h

my-config          2      37m

my-config-2        1      33m

my-config-3        2      31m

nginxconf          1      15s

[root@node22 configmap]# kubectl describe cm nginxconf

Name:         nginxconf

Namespace:    default

Labels:

Annotations:

Data

====

nginx.conf:

----

server {

    listen 8000;

    server_name _;

    location / {

        root /usr/share/nginx/html;

        index index.html index.htm;

    }

}

BinaryData

====

Events:

[root@node22 configmap]# vim nginx.yaml

apiVersion: apps/v1

kind: Deployment

metadata:

name: my-nginx

spec:

replicas: 1

selector:

    matchLabels:

      app: nginx

template:

    metadata:

      labels:

        app: nginx

    spec:

      containers:

        - name: nginx

          image: nginx

          volumeMounts:

            mountPath: /etc/nginx/conf.d

      volumes:

        - name: config-volume

          configMap:

            name: nginxconf

[root@node22 configmap]# kubectl apply -f nginx.yaml

deployment.apps/my-nginx created

[root@node22 ~]# cd calico/

[root@node22 calico]# kubectl delete -f networkpolicy.yaml

networkpolicy.networking.k8s.io "test-network-policy" deleted

[root@node22 calico]# cd

[root@node22 ~]# cd configmap/

[root@node22 configmap]# curl 10.244.144.76

curl: (7) Failed connect to 10.244.144.76:80; Connection refused

[root@node22 configmap]# kubectl edit cm nginxconf

##编辑nginxconf这个configmap将其端口修改为8080

[root@node22 configmap]# kubectl exec my-nginx-7b84dc948c-f6vlb -- cat /etc/nginx/conf.d/nginx.conf

server {

    listen 8080;

    server_name _;

    location / {

        root /usr/share/nginx/html;

        index index.html index.htm;

    }

}

[root@node22 configmap]# curl 10.244.144.76:8080

curl: (7) Failed connect to 10.244.144.76:8080; Connection refused

##此时虽然容器内的文件内容会更新（有一定延迟），但是更新的设定并没有生效；需要手动触发Pod滚动更新, 这样才能再次加载nginx.conf配置文件

[root@node22 configmap]# kubectl delete pod my-nginx-7b84dc948c-qmq9h

pod "my-nginx-7b84dc948c-qmq9h" deleted

root@node22 configmakubectl get pod -o wide

NAME                        READY   STATUS    RESTARTS AGE   IP              NODE     NOMINATED NODE   READINESS GATES

my-nginx-7b84dc948c-qxgtb   1/1     Running   0          5s    10.244.144.80   node33

[root@node22 configmap]# curl 10.244.144.80:8080

Welcome to nginx!

Welcome to nginx!

If you see this page, the nginx web server is successfully installed and

working. Further configuration is required.

For online documentation and support please refer to

nginx.org.

Commercial support is available at

nginx.com.

Thank you for using nginx.

再改回8000

[root@node22 configmap]# kubectl edit cm nginxconf

[root@node22 configmap]# kubectl patch deployments.apps my-nginx --patch '{"spec": {"template": {"metadata": {"annotations": {"version/config": "20220827"}}}}}'

deployment.apps/my-nginx patched

[root@node22 configmap]# kubectl get all

NAME                            READY   STATUS    RESTARTS   AGE

pod/my-nginx-645f5bbfd6-lrmtp   1/1     Running   0          10s

NAME                  TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)   AGE

service/kubernetes    ClusterIP   10.96.0.1                443/TCP   3d6h

service/my-svc        ClusterIP   10.108.185.37            80/TCP    9h

service/web-service   ClusterIP   10.109.238.119           80/TCP    38h

NAME                       READY   UP-TO-DATE   AVAILABLE   AGE

deployment.apps/my-nginx   1/1     1            1           30m

NAME                                  DESIRED   CURRENT   READY   AGE

replicaset.apps/my-nginx-645f5bbfd6   1         1         1       10s

replicaset.apps/my-nginx-7b84dc948c   0         0         0       30m

二、Secret配置管理

Secret对象类型用来保存敏感信息，例如密码、OAuth令牌和ssh key；敏感信息放在secret中比放在Pod的定义或者容器镜像中来说更加安全和灵活

Pod可以用两种方式使用secret：作为volume中的文件被挂载到pod中的一个或者多个容器里；当 kubelet为pod拉取镜像时使用

Secret的类型：

Service Account：Kubernetes自动创建包含访问API凭据的secret，并自动修改pod以使用此类型的secret

Opaque：使用base64编码存储信息，可以通过base64 --decode解码获得原始数据，因此安全性弱，Opaque类型的Secret其value为base64编码后的值

kubernetes.io/dockerconfigjson：用于存储docker registry的认证信息


1.##serviceaccout创建时Kubernetes会默认创建对应的secret，对应的secret会自动挂载到Pod的 /var/run/secrets/kubernetes.io/serviceaccount目录中
[root@node22 ~]# kubectl get pod
NAME                        READY   STATUS    RESTARTS      AGE
my-nginx-645f5bbfd6-lrmtp   1/1     Running   1 (49m ago)   13h
[root@node22 ~]# kubectl describe pod
 Mounts:
      /etc/nginx/conf.d from config-volume (rw)
      /var/run/secrets/kubernetes.io/serviceaccount from kube-api-access-r9k7t (ro)
[root@node22 ~]# kubectl exec my-nginx-645f5bbfd6-lrmtp -- ls /var/run/secrets/kubernetes.io/serviceaccount
ca.crt
namespace
token

##每个namespace下有一个名为default的默认的ServiceAccount对象
[root@node22 ~]# kubectl get sa
NAME      SECRETS   AGE
default   1         3d20h
[root@node22 ~]# kubectl get sa -n test
NAME      SECRETS   AGE
default   1         16h

2.##ServiceAccount里有一个名为Tokens的可以作为Volume一样被Mount到Pod里的Secret，当Pod启动时这个Secret会被自动Mount到Pod的指定目录下，用来协助完成Pod中的进程访问API Server时的身份鉴权过程
[root@node22 ~]# kubectl get pod my-nginx-645f5bbfd6-lrmtp -o yaml
spec:
  containers:
  - image: nginx
    imagePullPolicy: Always
    name: nginx
    resources: {}
    terminationMessagePath: /dev/termination-log
    terminationMessagePolicy: File
    volumeMounts:
    - mountPath: /etc/nginx/conf.d
      name: config-volume
    - mountPath: /var/run/secrets/kubernetes.io/serviceaccount
      name: kube-api-access-r9k7t
      readOnly: true

3.##从文件中创建secret
[root@node22 ~]# cd secret/
[root@node22 secret]# echo -n 'admin' > ./username.txt
[root@node22 secret]# echo -n 'westos' > ./password.txt
[root@node22 secret]# kubectl create secret generic db-user-pass --from-file=./username.txt --from-file=./password.txt
secret/db-user-pass created
[root@node22 secret]# kubectl get secrets
NAME                  TYPE                                  DATA   AGE
basic-auth            Opaque                                1      23h
db-user-pass          Opaque                                2      28s
default-token-pf6bb   kubernetes.io/service-account-token   3      3d20h
tls-secret            kubernetes.io/tls                     2      23h
[root@node22 secret]# kubectl describe secrets db-user-pass
Name:         db-user-pass
Namespace:    default
Labels:       <none>
Annotations:  <none>

Type:  Opaque

Data
====
password.txt:  6 bytes
username.txt:  5 bytes
默认情况下 kubectl get和kubectl describe 为了安全是不会显示密码的内容,可以
通过以下方式查看：
如果密码具有特殊字符，则需要使用 \ 字符对其进行转义，执行以下命令：
kubectl create secret generic dev-db-secret --from-literal=username=devuser
--from-literal=password=S\!B\\*d\$zDs

[root@node22 secret]# kubectl get  secrets db-user-pass -o yaml
apiVersion: v1
data:
  password.txt: d2VzdG9z
  username.txt: YWRtaW4=
kind: Secret
metadata:
  creationTimestamp: "2022-08-28T09:59:53Z"
  name: db-user-pass
  namespace: default
  resourceVersion: "187151"
  uid: 2630512d-c437-4d41-bdc8-a4748df06835
type: Opaque
查看密码可以采用下面方法：
[root@node22 secret]# echo d2VzdG9z | base64 -d
westos
[root@node22 secret]# echo YWRtaW4= | base64 -d
admin

4.##从yaml文件创建secret
[root@node22 secret]# vim secret.yaml
apiVersion: v1
kind: Secret
metadata:
  name: mysecret
type: Opaque
data:
  username: YWRtaW4=
  password: d2VzdG9z
[root@node22 secret]# kubectl apply -f secret.yaml
secret/mysecret created
[root@node22 secret]# kubectl get secrets mysecret -o yaml
apiVersion: v1
data:
  password: d2VzdG9z
  username: YWRtaW4=
kind: Secret
metadata:
  annotations:
    kubectl.kubernetes.io/last-applied-configuration: |
      {"apiVersion":"v1","data":{"password":"d2VzdG9z","username":"YWRtaW4="},"kind":"Secret","metadata":{"annotations":{},"name":"mysecret","namespace":"default"},"type":"Opaque"}
  creationTimestamp: "2022-08-28T10:08:23Z"
  name: mysecret
  namespace: default
  resourceVersion: "188013"
  uid: cbba6019-bad6-4e95-8acb-b53b9d022bea
type: Opaque

##将secrect通过volume挂载到pod中
[root@node22 secret]# vim pod.yaml
apiVersion: v1
kind: Pod
metadata:
  name: mysecret
spec:
  containers:
  - name: nginx
    image: nginx
    volumeMounts:
    - name: secrets
      mountPath: "/secret"
      readOnly: true
  volumes:
  - name: secrets
    secret:
      secretName: mysecret
[root@node22 secret]# kubectl apply -f pod.yaml
pod/mysecret created
[root@node22 secret]# kubectl get pod
NAME                        READY   STATUS    RESTARTS      AGE
my-nginx-645f5bbfd6-lrmtp   1/1     Running   1 (75m ago)   14h
mysecret                    1/1     Running   0             10s
[root@node22 secret]# kubectl exec mysecret -- ls /secret
password
username

5.##向指定路径映射secret的键值
[root@node22 secret]# vim pod2.yaml
apiVersion: v1
kind: Pod
metadata:
  name: mysecret
spec:
  containers:
  - name: nginx
    image: nginx
    volumeMounts:
    - name: secrets
      mountPath: "/secret"
      readOnly: true
  volumes:
  - name: secrets
    secret:
      secretName: mysecret
      items:
      - key: username
        path: my-group/my-username
[root@node22 secret]# kubectl apply -f  pod2.yaml
pod/mysecret created
[root@node22 secret]# kubectl get pod
NAME                        READY   STATUS    RESTARTS      AGE
my-nginx-645f5bbfd6-lrmtp   1/1     Running   1 (79m ago)   14h
mysecret                    1/1     Running   0             6s
[root@node22 secret]# kubectl exec mysecret -- ls /secret
my-group
[root@node22 secret]# kubectl exec mysecret -- ls /secret/my-group
my-username
[root@node22 secret]# kubectl exec mysecret -- cat /secret/my-group/my-username
admin

##kubernetes.io/dockerconfigjson用于存储docker registry的认证信息
[root@node22 secret]# vim docker.yaml
apiVersion: v1
kind: Pod
metadata:
  name: mypod
spec:
  containers:
    - name: game2048
      image: reg.westos.org/westos/game2048
  #imagePullSecrets:   不做认证
  #  - name: myregistrykey
[root@node22 secret]# kubectl apply -f docker.yaml
pod/mypod created
[root@node22 secret]# kubectl get pod  镜像拉取失败
NAME    READY   STATUS             RESTARTS   AGE
mypod   0/1     ImagePullBackOff   0          14s
[root@node22 secret]#  kubectl create secret docker-registry myregistrykey --docker-server=reg.westos.org --docker-username=admin --docker-password=westos --docker-email=zcx0216@westos.org
secret/myregistrykey created   做认证
[root@node22 secret]# kubectl get secrets
NAME                  TYPE                                  DATA   AGE
basic-auth            Opaque                                1      23h
db-user-pass          Opaque                                2      28m
default-token-pf6bb   kubernetes.io/service-account-token   3      3d21h
myregistrykey         kubernetes.io/dockerconfigjson        1      40s认证信息
mysecret              Opaque                                2      20m
tls-secret            kubernetes.io/tls                     2      23h
[root@node22 secret]# vim docker.yaml
apiVersion: v1
kind: Pod
metadata:
  name: mypod
spec:
  containers:
    - name: game2048
      image: reg.westos.org/westos/game2048
  imagePullSecrets:
    - name: myregistrykey
[root@node22 secret]# kubectl apply -f docker.yaml
pod/mypod created
[root@node22 secret]# kubectl get pod
NAME    READY   STATUS    RESTARTS   AGE
mypod   1/1     Running   0          6s
[root@node22 secret]# kubectl delete -f docker.yaml
pod "mypod" deleted

三、Volumes配置管理

容器中的文件在磁盘上是临时存放的，这给容器中运行的特殊应用程序带来一些问题，首先，当容器崩溃时，kubelet将重新启动容器，容器中的文件将会丢失，因为容器会以干净的状态重建；其次，当在一个Pod中同时运行多个容器时，常常需要在这些容器之间共享文件；Kubernetes抽象出 Volume对象来解决这两个问题

Kubernetes卷具有明确的生命周期，与包裹它的Pod相同；因此，卷比Pod中运行的任何容器的存活期都长，在容器重新启动时数据也会得到保留；当一个Pod不再存在时，卷也将不再存在；也许更重要的是，Kubernetes可以支持许多类型的卷，Pod也能同时使用任意数量的卷

卷不能挂载到其他卷，也不能与其他卷有硬链接；Pod中的每个容器必须独立地指定每个卷的挂载位置

Kubernetes 支持下列类型的卷：

awsElasticBlockStore 、azureDisk、azureFile、cephfs、cinder、configMap、csi、downwardAPI、emptyDir、fc (fibre channel)、flexVolume、flocker gcePersistentDisk、gitRepo(deprecated)、glusterfs、hostPath、iscsi、local、 nfs、persistentVolumeClaim、projected、portworxVolume、quobyte、rbd scaleIO、secret、storageos、vsphereVolume

1).emptyDir卷：

当Pod指定到某个节点上时，首先创建的是一个emptyDir卷，并且只要Pod在该节点上运行，卷就一直存在；就像其名称表示的那样，卷最初是空的；尽管Pod中的容器挂载emptyDir卷的路径可能相同也可能不同，但是这些容器都可以读写emptyDir卷中相同的文件；当Pod因为某些原因被从节点上删除时，emptyDir卷中的数据也会永久删除

emptyDir的使用场景：缓存空间，例如基于磁盘的归并排序；为耗时较长的计算任务提供检查点，以便任务能方便地从崩溃前状态恢复执行；在Web服务器容器服务数据时，保存内容管理器容器获取的文件

默认情况下，emptyDir卷存储在支持该节点所使用的介质上，这里的介质可以是磁盘或SSD或网络存储，这取决于您的环境；但是，您可以将emptyDir.medium字段设置为"Memory"，以告诉Kubernetes为您安装tmpfs（基于内存的文件系统）；虽然tmpfs速度非常快，但是要注意它与磁盘不同，tmpfs在节点重启时会被清除，并且您所写入的所有文件都会计入容器的内存消耗，受容器内存限制约束


[root@node22 secret]# cd
[root@node22 ~]#  mkdir volumes
[root@node22 ~]# cd volumes/
[root@node22 volumes]# vim vol1.yaml
apiVersion: v1
kind: Pod
metadata:
  name: vol1
spec:
  containers:
  - image: busyboxplus
    name: vm1
    command: ["sleep", "300"]
    volumeMounts:
    - mountPath: /cache
      name: cache-volume
  - name: vm2
    image: nginx
    volumeMounts:
    - mountPath: /usr/share/nginx/html
      name: cache-volume
  volumes:
  - name: cache-volume
    emptyDir:
      medium: Memory
      sizeLimit: 100Mi
[root@node22 volumes]# kubectl apply -f vol1.yaml
pod/vol1 created
[root@node22 volumes]# kubectl get pod
NAME   READY   STATUS    RESTARTS   AGE
vol1   2/2     Running   0          4s
[root@node22 volumes]# kubectl exec -it vol1 -c vm1 -- sh
/ # ls
bin      cache    dev      etc      home     lib      lib64    linuxrc  media    mnt      opt      proc     root     run      sbin     sys      tmp      usr      var
/ # cd cache/
/cache # ls
/cache # echo www.westos.org > index.html
/cache # curl localhost
www.westos.org
/cache # dd if=/dev/zero of=bigfile bs=1M count=100
100+0 records in
99+1 records out
/cache # dd if=/dev/zero of=bigfile bs=1M count=101
dd: writing 'bigfile': No space left on device
101+0 records in
99+1 records out

2).hostPath卷

hostPath卷能将主机节点文件系统上的文件或目录挂载到Pod中，虽然这不是大多数Pod需要的，但是它为一些应用程序提供了强大的逃生舱

hostPath卷的一些用法：运行一个需要访问Docker引擎内部机制的容器，挂载/var/lib/docker路径；在容器中运行cAdvisor时，以hostPath方式挂载 /sys；允许Pod指定给定的hostPath在运行Pod之前是否应该存在，是否应该创建以及应该以什么方式存在

除了必需的path属性之外，用户可以选择性地为hostPath卷指定type

hostPath卷的缺点：具有相同配置（例如从podTemplate创建）的多个Pod会由于节点上文件的不同而在不同节点上有不同的行为；当Kubernetes按照计划添加资源感知的调度时，这类调度机制将无法考虑由hostPath使用的资源；基础主机上创建的文件或目录只能由root用户写入；您需要在特权容器中以root身份运行进程，或者修改主机上的文件权限以便容器能够写入hostPath卷


[root@node22 volumes]# kubectl delete -f vol1.yaml
pod "vol1" deleted
[root@node22 volumes]# vim hostpath.yaml
apiVersion: v1
kind: Pod
metadata:
  name: test-pd
spec:
  containers:
  - image: nginx
    name: test-container
    volumeMounts:
    - mountPath: /usr/share/nginx/html
      name: test-volume
  volumes:
  - name: test-volume
    hostPath:
      path: /data
      type: DirectoryOrCreate
[root@node22 volumes]# kubectl apply -f hostpath.yaml  生效
pod/test-pd created
[root@node22 volumes]# kubectl get pod
NAME      READY   STATUS    RESTARTS   AGE
test-pd   1/1     Running   0          10s
[root@node22 volumes]# kubectl get pod -o wide  分配到了node33
NAME      READY   STATUS    RESTARTS   AGE   IP              NODE     NOMINATED NODE   READINESS GATES
test-pd   1/1     Running   0          62s   10.244.144.90   node33   <none>           <none>
[root@node22 volumes]# curl 10.244.144.90  访问时报错，再node33主机创建首页即可解决
<html>
<head><title>403 Forbidden</title></head>
<body>
<center><h1>403 Forbidden</h1></center>
<hr><center>nginx/1.21.5</center>
</body>
</html>

[root@node33 ~]# cd /data
[root@node33 data]# ls
[root@node33 data]# pwd
/data
[root@node33 data]# echo www.westos.org > index.html
此时再次访问就没有问题
[root@node22 volumes]# curl 10.244.144.90
www.westos.org

如果pod被迁移到node44上：
[root@node44 ~]# mkdir /data
[root@node44 ~]# cd /data/
[root@node44 data]# ls
[root@node44 data]# echo bbs.westos.org > index.html

[root@node22 volumes]# kubectl delete -f hostpath.yaml
pod "test-pd" deleted
[root@node22 volumes]# vim hostpath.yaml  做迁移
apiVersion: v1
kind: Pod
metadata:
  name: test-pd
spec:
  containers:
  - image: nginx
    name: test-container
    volumeMounts:
    - mountPath: /usr/share/nginx/html
      name: test-volume
  volumes:
  - name: test-volume
    hostPath:
      path: /data
      type: DirectoryOrCreate
  nodeName: node44
[root@node22 volumes]# kubectl apply -f hostpath.yaml
pod/test-pd created
[root@node22 volumes]# kubectl get pod -o wide已经迁移到node44
NAME      READY   STATUS    RESTARTS   AGE   IP               NODE     NOMINATED NODE   READINESS GATES
test-pd   1/1     Running   0          38s   10.244.214.130   node44   <none>           <none>
[root@node22 volumes]# curl 10.244.214.130此时访问的就是node44主机的页面
bbs.westos.org
[root@node22 volumes]# kubectl delete -f hostpath.yaml
pod "test-pd" deleted

3).nfs卷

在每个节点上安装nfs


[root@node22 volumes]#  yum install -y nfs-utils
[root@node33 data]#  yum install -y nfs-utils
[root@node44 data]#  yum install -y nfs-utils
[root@node11 harbor]# yum install -y nfs-utils  仓库上安装nfs
[root@node11 harbor]# cat /etc/exports
/nfsdata        *(rw,no_root_squash)
[root@node11 harbor]# mkdir /nfsdata
[root@node11 harbor]# cd /nfsdata/
[root@node11 nfsdata]# chmod 777 .
[root@node11 nfsdata]# ll -d .
drwxrwxrwx 2 root root 6 Aug 28 20:40 .
[root@node11 nfsdata]# systemctl start nfs
[root@node11 nfsdata]# echo www.westos.org > index.html


[root@node22 volumes]# showmount -e 192.168.0.11
Export list for 192.168.0.11:
/nfsdata *
[root@node22 volumes]# vim nfs.yaml
apiVersion: v1
kind: Pod
metadata:
  name: test-pd
spec:
  containers:
  - image: nginx
    name: test-container
    volumeMounts:
    - mountPath: /usr/share/nginx/html
      name: test-volume
  volumes:
  - name: test-volume
    nfs:
      server: 192.168.0.11
      path: /nfsdata
[root@node22 volumes]# kubectl apply -f nfs.yaml
pod/test-pd created
[root@node22 volumes]# kubectl get pod -o wide
NAME      READY   STATUS    RESTARTS   AGE   IP              NODE     NOMINATED NODE   READINESS GATES
test-pd   1/1     Running   0          20s   10.244.144.91   node33   <none>           <none>
[root@node22 volumes]# curl 10.244.144.91
www.westos.org
[root@node22 volumes]# kubectl delete -f nfs.yaml删除后迁移到
pod "test-pd" deleted
[root@node22 volumes]# vim nfs.yaml
apiVersion: v1
kind: Pod
metadata:
  name: test-pd
spec:
  containers:
  - image: nginx
    name: test-container
    volumeMounts:
    - mountPath: /usr/share/nginx/html
      name: test-volume
  volumes:
  - name: test-volume
    nfs:
      server: 192.168.0.11
      path: /nfsdata
  nodeName: node44   迁移到node44
[root@node22 volumes]# kubectl apply -f nfs.yaml
pod/test-pd created
[root@node22 volumes]# kubectl get pod
NAME      READY   STATUS    RESTARTS   AGE
test-pd   1/1     Running   0          39s
[root@node22 volumes]# kubectl get pod -o wide
NAME      READY   STATUS    RESTARTS   AGE     IP               NODE     NOMINATED NODE   READINESS GATES
test-pd   1/1     Running   0          2m17s   10.244.214.131   node44   <none>           <none>
[root@node22 volumes]# curl 10.244.214.131
www.westos.org

4).持久卷PV与持久卷声明PVC

PersistentVolume是集群内，由管理员提供的网络存储的一部分，就像集群中的节点一样，PV也是集群中的一种资源，它也像Volume一样，是一种volume插件，但是它的生命周期却是和使用它的Pod相互独立的；PV这个API对象，捕获了诸如NFS、ISCSI、或其他云存储系统的实现细节

PersistentVolumeClaim是用户的一种存储请求，它和Pod类似，Pod消耗Node资源，而PVC消耗PV资源；Pod能够请求特定的资源（如CPU和内存），PVC能够请求指定的大小和访问的模式（可以被映射为一次读写或者多次只读）

有两种PV提供的方式：静态和动态

静态PV：集群管理员创建多个PV，它们携带着真实存储的详细信息，这些存储对于集群用户是可用的，它们存在于Kubernetes API中，并可用于存储使用

动态PV：当管理员创建的静态PV都不匹配用户的PVC时，集群可能会尝试专门地供给volume给PVC，这种供给基于StorageClass

PVC与PV的绑定是一对一的映射，没找到匹配的PV，那么PVC会无限期处于unbound即未绑定状态

PV使用：

Pod使用PVC就像使用volume一样；集群检查PVC，查找绑定的PV，并映射PV给Pod，对于支持多种访问模式的PV，用户可以指定想用的模式；一旦用户拥有了一个PVC，并且PVC被绑定，那么只要用户还需要，PV就一直属于这个用户；用户调度Pod，通过在Pod的volume块中包含PVC来访问PV

PV释放：

当用户使用PV完毕后，他们可以通过API来删除PVC对象，当PVC被删除后，对应的PV就被认为是已经是“released”了，但还不能再给另外一个PVC使用，前一个PVC的属于还存在于该PV中，必须根据策略来处理掉

PV回收：

PV的回收策略告诉集群，在PV被释放之后集群应该如何处理该PV；当前，PV可以被Retained（保留）、Recycled（再利用）或者Deleted（删除）；保留允许手动地再次声明资源，对于支持删除操作的PV卷，删除操作会从Kubernetes中移除PV对象，还有对应的外部存储（如AWS EBS、GCE PD、Azure Disk或者Cinder volume）；动态供给的卷总是会被删除

##创建不同容量和访问模式的两个pv

访问模式：ReadWriteOnce（RWO）==该volume只能被单个节点以读写的方式映射；ReadOnlyMany（ROX）==该volume可以被多个节点以只读方式映射；ReadWriteMany（RWX）==该volume可以被多个节点以读写的方式映射

回收策略：Retain==保留，需要手动回收；Recycle==回收，自动删除卷中数据；Delete==删除，相关联的存储资产，如AWS EBS，GCE PD，Azure Disk，or OpenStack Cinder卷都会被删除

当前只有NFS卷和HostPath卷支持回收利用，AWS EBS、GCE PD、Azure Disk、OpenStack Cinder卷支持删除操作

状态：Available==空闲的资源，未绑定给PVC；Bound==绑定给了某个PVC；Released==PVC已经删除了，但是PV还没有被集群回收；Failed==PV在自动回收中失败了


[root@node11 nfsdata]# mkdir pv1
[root@node11 nfsdata]# mkdir pv2
[root@node11 nfsdata]# mkdir pv3

[root@node22 volumes]# vim pv.yaml
apiVersion: v1
kind: PersistentVolume
metadata:
  name: pv0003
spec:
  capacity:
    storage: 5Gi
  volumeMode: Filesystem
  accessModes:
    - ReadWriteOnce
  persistentVolumeReclaimPolicy: Recycle
  storageClassName: nfs
  mountOptions:
  nfs:
    path: /nfsdata/pv1
    server: 192.168.0.11
[root@node22 volumes]# kubectl apply -f pv.yaml
persistentvolume/pv0003 created
[root@node22 volumes]# kubectl get pv
NAME     CAPACITY   ACCESS MODES   RECLAIM POLICY   STATUS      CLAIM   STORAGECLASS   REASON   AGE
pv0003   5Gi        RWO            Recycle          Available           nfs                     7s


##创建pvc，pvc会根据文件中定义的存储类、容量需求和访问模式匹配到合适的pv进行绑定[root@node22 volumes]# vim pvc.yaml
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: pvc1
spec:
  storageClassName: nfs
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 1Gi
[root@node22 volumes]# kubectl apply -f pvc.yaml
persistentvolumeclaim/pvc1 created
[root@node22 volumes]# kubectl get pvc
NAME   STATUS   VOLUME   CAPACITY   ACCESS MODES   STORAGECLASS   AGE
pvc1   Bound    pv0003   5Gi        RWO            nfs            25s
[root@node22 volumes]# kubectl get pv
NAME     CAPACITY   ACCESS MODES   RECLAIM POLICY   STATUS   CLAIM          STORAGECLASS   REASON   AGE
pv0003   5Gi        RWO            Recycle          Bound    default/pvc1   nfs                     3m41s

##pod中挂载pv
[root@node22 volumes]# vim pod.yaml
apiVersion: v1
kind: Pod
metadata:
  name: test-pd
spec:
  containers:
  - image: nginx
    name: nginx
    volumeMounts:
    - mountPath: /usr/share/nginx/html
      name: vol1
  volumes:
  - name: vol1
    persistentVolumeClaim:
      claimName: pvc1
[root@node22 volumes]# kubectl delete pod test-pd
pod "test-pd" deleted
[root@node22 volumes]# kubectl apply -f pod.yaml
pod/test-pd created

[root@node11 nfsdata]# cd pv1
[root@node11 pv1]# echo pv1 > index.html

[root@node22 volumes]# kubectl get pod -o wide
NAME      READY   STATUS    RESTARTS   AGE     IP              NODE     NOMINATED NODE   READINESS GATES
test-pd   1/1     Running   0          2m37s   10.244.144.92   node33   <none>           <none>
[root@node22 volumes]# curl 10.244.144.92
pv1

创建pv2,pv3
[root@node22 volumes]# vim pv.yaml
apiVersion: v1
kind: PersistentVolume
metadata:
  name: pv0003
spec:
  capacity:
    storage: 5Gi
  volumeMode: Filesystem
  accessModes:
    - ReadWriteOnce
  persistentVolumeReclaimPolicy: Recycle
  storageClassName: nfs
  mountOptions:
  nfs:
    path: /nfsdata/pv1
    server: 192.168.0.11

---
apiVersion: v1
kind: PersistentVolume
metadata:
  name: pv2
spec:
  capacity:
    storage: 10Gi
  volumeMode: Filesystem
  accessModes:
    - ReadWriteMany
  persistentVolumeReclaimPolicy: Recycle
  storageClassName: nfs
  mountOptions:
  nfs:
    path: /nfsdata/pv2
    server: 192.168.0.11

---
apiVersion: v1
kind: PersistentVolume
metadata:
  name: pv3
spec:
  capacity:
    storage: 20Gi
  volumeMode: Filesystem
  accessModes:
    - ReadOnlyMany
  persistentVolumeReclaimPolicy: Recycle
  storageClassName: nfs
  mountOptions:
  nfs:
    path: /nfsdata/pv3
    server: 192.168.0.11
[root@node22 volumes]# kubectl apply -f pv.yaml
persistentvolume/pv0003 configured
persistentvolume/pv2 created
persistentvolume/pv3 created
[root@node22 volumes]# kubectl get pv
NAME     CAPACITY   ACCESS MODES   RECLAIM POLICY   STATUS      CLAIM          STORAGECLASS   REASON   AGE
pv0003   5Gi        RWO            Recycle          Bound       default/pvc1   nfs                     15m
pv2      10Gi       RWX            Recycle          Available                  nfs                     12s
pv3      20Gi       ROX            Recycle          Available                  nfs                     12s

创建pvc2,pvc3
[root@node22 volumes]# vim pvc.yaml
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: pvc1
spec:
  storageClassName: nfs
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 1Gi

---
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: pvc2
spec:
  storageClassName: nfs
  accessModes:
    - ReadWriteMany
  resources:
    requests:
      storage: 10Gi

---
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: pvc3
spec:
  storageClassName: nfs
  accessModes:
    - ReadOnlyMany
  resources:
    requests:
      storage: 20Gi
[root@node22 volumes]# kubectl apply -f pvc.yaml
persistentvolumeclaim/pvc1 unchanged
persistentvolumeclaim/pvc2 created
persistentvolumeclaim/pvc3 created
[root@node22 volumes]# kubectl get pvc
NAME   STATUS   VOLUME   CAPACITY   ACCESS MODES   STORAGECLASS   AGE
pvc1   Bound    pv0003   5Gi        RWO            nfs            14m
pvc2   Bound    pv2      10Gi       RWX            nfs            6s
pvc3   Bound    pv3      20Gi       ROX            nfs            6s
[root@node22 volumes]# kubectl get pv
NAME     CAPACITY   ACCESS MODES   RECLAIM POLICY   STATUS   CLAIM          STORAGECLASS   REASON   AGE
pv0003   5Gi        RWO            Recycle          Bound    default/pvc1   nfs                     18m
pv2      10Gi       RWX            Recycle          Bound    default/pvc2   nfs                     3m7s
pv3      20Gi       ROX            Recycle          Bound    default/pvc3   nfs                     3m7s

创建test-pd-2
[root@node22 volumes]# cp pod.yaml pod2.yaml
[root@node22 volumes]# vim pod2.yaml
apiVersion: v1
kind: Pod
metadata:
  name: test-pd-2
spec:
  containers:
  - image: nginx
    name: nginx
    volumeMounts:
    - mountPath: /usr/share/nginx/html
      name: vol2
  volumes:
  - name: vol2
    persistentVolumeClaim:
      claimName: pvc2
[root@node22 volumes]# kubectl apply -f pod2.yaml
pod/test-pd-2 created
[root@node22 volumes]# kubectl get pod
NAME        READY   STATUS    RESTARTS   AGE
test-pd     1/1     Running   0          11m
test-pd-2   1/1     Running   0          15s
[root@node22 volumes]# kubectl get pod -o wide
NAME        READY   STATUS    RESTARTS   AGE   IP              NODE     NOMINATED NODE   READINESS GATES
test-pd     1/1     Running   0          12m   10.244.144.92   node33   <none>           <none>
test-pd-2   1/1     Running   0          93s   10.244.144.93   node33   <none>           <none>
[root@node11 pv1]# cd ..
[root@node11 nfsdata]# cd pv2
[root@node11 pv2]# echo pv2 > index.html
[root@node22 volumes]# curl 10.244.144.93
pv2
[root@node22 volumes]# curl 10.244.144.92
pv1

删除：（pod被迁移到其他节点的时候，再次挂接pvc）
[root@node22 volumes]# kubectl delete -f pod2.yaml
pod "test-pd-2" deleted
[root@node22 volumes]# kubectl delete -f pod.yaml
pod "test-pd" deleted
[root@node22 volumes]# kubectl get pvc
NAME   STATUS   VOLUME   CAPACITY   ACCESS MODES   STORAGECLASS   AGE
pvc1   Bound    pv0003   5Gi        RWO            nfs            25m
pvc2   Bound    pv2      10Gi       RWX            nfs            11m
pvc3   Bound    pv3      20Gi       ROX            nfs            11m

##删除pvc，先前被绑定的pv的状态由bound->released->available；挂载卷中数据被删除（recycle的回收策略）
[root@node22 volumes]# kubectl delete -f pvc.yaml
persistentvolumeclaim "pvc1" deleted
persistentvolumeclaim "pvc2" deleted
persistentvolumeclaim "pvc3" deleted
[root@node22 volumes]# kubectl get pv
NAME     CAPACITY   ACCESS MODES   RECLAIM POLICY   STATUS      CLAIM   STORAGECLASS   REASON   AGE
pv0003   5Gi        RWO            Recycle          Available           nfs                     31m
pv2      10Gi       RWX            Recycle          Available           nfs                     16m
pv3      20Gi       ROX            Recycle          Available           nfs                     16m
[root@node22 volumes]# kubectl get pod
NAME                  READY   STATUS      RESTARTS   AGE
recycler-for-pv0003   0/1     Completed   0          89s
[root@node22 volumes]# kubectl delete pod recycler-for-pv0003
pod "recycler-for-pv0003" deleted
[root@node22 volumes]# kubectl get pv
NAME     CAPACITY   ACCESS MODES   RECLAIM POLICY   STATUS      CLAIM   STORAGECLASS   REASON   AGE
pv0003   5Gi        RWO            Recycle          Available           nfs                     33m
pv2      10Gi       RWX            Recycle          Available           nfs                     18m
pv3      20Gi       ROX            Recycle          Available           nfs                     18m
[root@node22 volumes]# kubectl delete -f pv.yaml
persistentvolume "pv0003" deleted
persistentvolume "pv2" deleted
persistentvolume "pv3" deleted
[root@node22 volumes]# kubectl get pv
No resources found

5).StorageClass提供了一种描述存储类（class）的方法，不同的class可能会映射到不同的服务质量等级和备份策略或其他策略等；每个StorageClass都包含provisioner、parameters和reclaimPolicy字段，这些字段会在StorageClass需要动态分配PersistentVolume时会使用到

StorageClass的属性：

Provisioner（存储分配器）：用来决定使用哪个卷插件分配PV，该字段必须指定，可以指定内部分配器，也可以指定外部分配器；外部分配器的代码地址为： kubernetes-incubator/external-storage，其中包括NFS和Ceph等

Reclaim Policy（回收策略）：通过reclaimPolicy字段指定创建的PersistentVolume的回收策略，回收策略包括：Delete或者Retain，没有指定默认为Delete

更多属性查看:https://kubernetes.io/zh/docs/concepts/storage/storage-classes/

NFS Client Provisioner是一个automatic provisioner，使用NFS作为存储，自动创建PV和对应的PVC，其本身不提供NFS存储，需要外部先有一套NFS存储服务

PV以 ${namespace}-${pvcName}-${pvName} 的命名格式提供（在NFS服务器上）；PV回收的时候以 archieved-${namespace}-${pvcName}-${pvName} 的命名格式（在NFS服务器上）；nfs-client-provisioner源码地址：external-storage/nfs-client at master · kubernetes-retired/external-storage · GitHub


##配置授权，编写yaml文件并应用，创建yaml文件中指定的namespace
[root@node22 ~]# mkdir nfs
[root@node22 ~]# cd nfs
[root@node22 nfs]# vim delpoyment.yaml
[root@node22 nfs]# kubectl create namespace nfs-client-provisioner
namespace/nfs-client-provisioner created
[root@node22 nfs]# vim delpoyment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: nfs-client-provisioner
  labels:
    app: nfs-client-provisioner
  namespace: nfs-client-provisioner
spec:
  replicas: 1
  strategy:
    type: Recreate
  selector:
    matchLabels:
      app: nfs-client-provisioner
  template:
    metadata:
      labels:
        app: nfs-client-provisioner
    spec:
      serviceAccountName: nfs-client-provisioner
      containers:
        - name: nfs-client-provisioner
          image: sig-storage/nfs-subdir-external-provisioner:v4.0.2
          volumeMounts:
            - name: nfs-client-root
              mountPath: /persistentvolumes
          env:
            - name: PROVISIONER_NAME
              value: k8s-sigs.io/nfs-subdir-external-provisioner
            - name: NFS_SERVER
              value: 192.168.0.11
            - name: NFS_PATH
              value: /nfsdata
      volumes:
        - name: nfs-client-root
          nfs:
            server: 192.168.0.11
            path: /nfsdata
[root@node22 nfs]# vim rbac.yaml
apiVersion: v1
kind: ServiceAccount
metadata:
  name: nfs-client-provisioner
  # replace with namespace where provisioner is deployed
  namespace: nfs-client-provisioner
---
kind: ClusterRole
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: nfs-client-provisioner-runner
rules:
  - apiGroups: [""]
    resources: ["nodes"]
    verbs: ["get", "list", "watch"]
  - apiGroups: [""]
    resources: ["persistentvolumes"]
    verbs: ["get", "list", "watch", "create", "delete"]
  - apiGroups: [""]
    resources: ["persistentvolumeclaims"]
    verbs: ["get", "list", "watch", "update"]
  - apiGroups: ["storage.k8s.io"]
    resources: ["storageclasses"]
    verbs: ["get", "list", "watch"]
  - apiGroups: [""]
    resources: ["events"]
    verbs: ["create", "update", "patch"]
---
kind: ClusterRoleBinding
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: run-nfs-client-provisioner
subjects:
  - kind: ServiceAccount
    name: nfs-client-provisioner
    # replace with namespace where provisioner is deployed
    namespace: nfs-client-provisioner
roleRef:
  kind: ClusterRole
  name: nfs-client-provisioner-runner
  apiGroup: rbac.authorization.k8s.io
---
kind: Role
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: leader-locking-nfs-client-provisioner
  # replace with namespace where provisioner is deployed
  namespace: nfs-client-provisioner
rules:
  - apiGroups: [""]
    resources: ["endpoints"]
    verbs: ["get", "list", "watch", "create", "update", "patch"]
---
kind: RoleBinding
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: leader-locking-nfs-client-provisioner
  # replace with namespace where provisioner is deployed
  namespace: nfs-client-provisioner
subjects:
  - kind: ServiceAccount
    name: nfs-client-provisioner
    # replace with namespace where provisioner is deployed
    namespace: nfs-client-provisioner
roleRef:
  kind: Role
  name: leader-locking-nfs-client-provisioner
  apiGroup: rbac.authorization.k8s.io
[root@node22 nfs]# kubectl apply -f rbac.yaml
serviceaccount/nfs-client-provisioner created
clusterrole.rbac.authorization.k8s.io/nfs-client-provisioner-runner created
clusterrolebinding.rbac.authorization.k8s.io/run-nfs-client-provisioner created
role.rbac.authorization.k8s.io/leader-locking-nfs-client-provisioner created
rolebinding.rbac.authorization.k8s.io/leader-locking-nfs-client-provisioner created
[root@node22 nfs]# kubectl apply -f delpoyment.yaml
deployment.apps/nfs-client-provisioner created
[root@node22 nfs]# kubectl -n nfs-client-provisioner get all
NAME                                        READY   STATUS    RESTARTS   AGE
pod/nfs-client-provisioner-784f85c9-mz5nx   1/1     Running   0          23s

NAME                                     READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/nfs-client-provisioner   1/1     1            1           23s

NAME                                              DESIRED   CURRENT   READY   AGE
replicaset.apps/nfs-client-provisioner-784f85c9   1         1         1       23s

##部署NFS Client Provisioner
[root@node22 nfs]# vim class.yaml
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: managed-nfs-storage
provisioner: k8s-sigs.io/nfs-subdir-external-provisioner
parameters:
  archiveOnDelete: "false"
[root@node22 nfs]# kubectl apply -f class.yaml
storageclass.storage.k8s.io/managed-nfs-storage created
[root@node22 nfs]# kubectl get storageclasses.storage.k8s.io
NAME                  PROVISIONER                                   RECLAIMPOLICY   VOLUMEBINDINGMODE   ALLOWVOLUMEEXPANSION   AGE
managed-nfs-storage   k8s-sigs.io/nfs-subdir-external-provisioner   Delete          Immediate           false                  21s

##创建NFS存储类
[root@node22 nfs]# vim pvc.yaml
kind: PersistentVolumeClaim
apiVersion: v1
metadata:
  name: test-claim
spec:
  storageClassName: managed-nfs-storage
  accessModes:
    - ReadWriteMany
  resources:
    requests:
      storage: 1Gi
[root@node22 nfs]# kubectl apply -f pvc.yaml
persistentvolumeclaim/test-claim created
[root@node22 nfs]# kubectl get pvc
NAME         STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS          AGE
test-claim   Bound    pvc-9506279b-4c3c-43eb-bebe-7cd89e6062d3   1Gi        RWX            managed-nfs-storage   3s
[root@node22 nfs]# kubectl get pv
NAME                                       CAPACITY   ACCESS MODES   RECLAIM POLICY   STATUS   CLAIM                STORAGECLASS          REASON   AGE
pvc-9506279b-4c3c-43eb-bebe-7cd89e6062d3   1Gi        RWX            Delete           Bound    default/test-claim   managed-nfs-storage            42s
[root@node22 nfs]# vim pod.yaml
apiVersion: v1
kind: Pod
metadata:
  name: test-pd
spec:
  containers:
  - image: nginx
    name: nginx
    volumeMounts:
    - mountPath: /usr/share/nginx/html
      name: nfs-pvc
  volumes:
  - name: nfs-pvc
    persistentVolumeClaim:
      claimName: test-claim
[root@node22 nfs]# kubectl apply -f pod.yaml
pod/test-pd created
[root@node22 nfs]# kubectl get pod
NAME      READY   STATUS    RESTARTS   AGE
test-pd   1/1     Running   0          8s
[root@node22 nfs]# kubectl get pod -o wide
NAME      READY   STATUS    RESTARTS   AGE   IP              NODE     NOMINATED NODE   READINESS GATES
test-pd   1/1     Running   0          30s   10.244.144.99   node33   <none>           <none>
[root@node22 nfs]# curl 10.244.144.99
<html>
<head><title>403 Forbidden</title></head>
<body>
<center><h1>403 Forbidden</h1></center>
<hr><center>nginx/1.21.5</center>
</body>
</html>

[root@node11 nfsdata]# cd default-test-claim-pvc-9506279b-4c3c-43eb-bebe-7cd89e6062d3
[root@node11 default-test-claim-pvc-9506279b-4c3c-43eb-bebe-7cd89e6062d3]# ls
[root@node11 default-test-claim-pvc-9506279b-4c3c-43eb-bebe-7cd89e6062d3]# echo test-claim > index.html

[root@node22 nfs]# curl 10.244.144.99
test-claim
[root@node22 nfs]# kubectl delete -f pod.yaml
pod "test-pd" deleted
[root@node22 nfs]# kubectl delete -f pvc.yaml
persistentvolumeclaim "test-claim" deleted
[root@node22 nfs]# kubectl get pv
No resources found
##删除上述pvc时，共享目录下自动创建的pv卷也被删除（因为class.yml文件中设定archiveOnDelete=false）

6).StatefulSet控制器

StatefulSet是用来管理有状态应用的工作负载API对象

StatefulSet用来管理Deployment和扩展一组Pod，并且能为这些Pod提供序号和唯一性保证

和Deployment相同的是，StatefulSet管理了基于相同容器定义的一组Pod，但和Deployment不同的是，StatefulSet为它们的每个Pod维护了一个固定的ID；这些Pod是基于相同的声明来创建的，但是不能相互替换：无论怎么调度，每个Pod都有一个永久不变的ID

StatefulSet和其他控制器使用相同的工作模式，在StatefulSet对象中定义你期望的状态，然后StatefulSet的控制器就会通过各种更新来达到那种你想要的状态

StatefulSets对于需要满足以下一个或多个需求的应用程序很有价值：

稳定的、唯一的网络标识符

稳定的、持久的存储

有序的、优雅的部署和缩放

有序的、自动的滚动更新

在上面，稳定意味着Pod调度或重调度的整个过程是有持久性的；如果应用程序不需要任何稳定的标识符或有序的部署、删除或伸缩，则应该使用由一组无状态的副本控制器提供的工作负载来部署应用程序，比如Deployment或者ReplicaSet可能更适用于无状态应用的部署需要


StatefulSet如何通过Headless Service维持Pod的拓扑状态:
创建headless svc:
[root@node22 statefulset]# vim svc.yaml
apiVersion: v1
kind: Service
metadata:
 name: nginx-svc
 labels:
  app: nginx
spec:
 ports:
 - port: 80
   name: web
 clusterIP: None
 selector:
  app: nginx
[root@node22 statefulset]# kubectl apply -f svc.yaml  生效yaml文件创建svc
service/nginx-svc created
[root@node22 statefulset]# kubectl get svc
NAME          TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)   AGE
kubernetes    ClusterIP   10.96.0.1        <none>        443/TCP   4d19h
my-svc        ClusterIP   10.108.185.37    <none>        80/TCP    45h
nginx-svc     ClusterIP   None             <none>        80/TCP    5s
web-service   ClusterIP   10.109.238.119   <none>        80/TCP    3d2h
[root@node22 statefulset]# kubectl delete svc my-svc删除不用的svc
service "my-svc" deleted
[root@node22 statefulset]# kubectl delete svc web-service
service "web-service" deleted
[root@node22 statefulset]# kubectl get svc
NAME         TYPE        CLUSTER-IP   EXTERNAL-IP   PORT(S)   AGE
kubernetes   ClusterIP   10.96.0.1    <none>        443/TCP   4d19h
nginx-svc    ClusterIP   None         <none>        80/TCP    33s

创建statefulSet控制器：
[root@node22 statefulset]# vim statefulset.yaml
apiVersion: apps/v1
kind: StatefulSet
metadata:
 name: web
spec:
 serviceName: "nginx-svc"
 replicas: 2
 selector:
  matchLabels:
   app: nginx
 template:
  metadata:
   labels:
    app: nginx
  spec:
   containers:
   - name: nginx
     image: nginx
[root@node22 statefulset]# kubectl apply -f statefulset.yaml
statefulset.apps/web created
[root@node22 statefulset]# kubectl get pod
NAME    READY   STATUS    RESTARTS   AGE
web-0   1/1     Running   0          2m20s
web-1   1/1     Running   0          49s
[root@node22 statefulset]# kubectl get pod -o wide
NAME    READY   STATUS    RESTARTS   AGE     IP               NODE     NOMINATED NODE   READINESS GATES
web-0   1/1     Running   0          2m49s   10.244.144.100   node33   <none>           <none>
web-1   1/1     Running   0          78s     10.244.214.132   node44   <none>           <none>

##statefulset控制器下pod的按顺序创建和回收：

StatefulSet将应用状态抽象成了两种情况：

拓扑状态：应用实例必须按照某种顺序启动；新创建的Pod必须和原来Pod的网络标识一样

存储状态：应用的多个实例分别绑定了不同存储数据

StatefulSet给所有的Pod进行了编号，编号规则是：$(statefulset名称)-$(序号)并且从0开始

Pod被删除后重建，重建Pod的网络标识也不会改变，Pod的拓扑状态按照“名字+编号”的方式固定下来，并且为每个Pod提供了一个固定且唯一的访问入口，即Pod对应的DNS记录

创建：（从第一个开始创建，第一个无法启动剩下的也无法创建）


[root@node22 statefulset]# dig -t A nginx-svc.default.svc.cluster.local. @10.96.0.10
; <<>> DiG 9.9.4-RedHat-9.9.4-72.el7 <<>> -t A nginx-svc.default.svc.cluster.local. @10.96.0.10
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 29984
;; flags: qr aa rd; QUERY: 1, ANSWER: 2, AUTHORITY: 0, ADDITIONAL: 1
;; WARNING: recursion requested but not available

;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 4096
;; QUESTION SECTION:
;nginx-svc.default.svc.cluster.local. IN        A

;; ANSWER SECTION:
nginx-svc.default.svc.cluster.local. 30 IN A    10.244.144.100
nginx-svc.default.svc.cluster.local. 30 IN A    10.244.214.132

;; Query time: 362 msec
;; SERVER: 10.96.0.10#53(10.96.0.10)
;; WHEN: Mon Aug 29 16:49:23 CST 2022
;; MSG SIZE  rcvd: 166
[root@node22 statefulset]# dig -t A web-0.nginx-svc.default.svc.cluster.local. @10.96.0.10
;; ANSWER SECTION:
web-0.nginx-svc.default.svc.cluster.local. 30 IN A 10.244.144.100
[root@node22 statefulset]# dig -t A web-1.nginx-svc.default.svc.cluster.local. @10.96.0.10
;; ANSWER SECTION:
web-1.nginx-svc.default.svc.cluster.local. 30 IN A 10.244.214.132
回收：（从最后一个开始回收）
[root@node22 statefulset]# vim statefulset.yaml
apiVersion: apps/v1
kind: StatefulSet
metadata:
 name: web
spec:
 serviceName: "nginx-svc"
 replicas: 0               将此处改为0即是回收，并不是delete
 selector:
  matchLabels:
   app: nginx
 template:
  metadata:
   labels:
    app: nginx
  spec:
   containers:
   - name: nginx
     image: nginx
[root@node22 statefulset]# kubectl apply -f statefulset.yaml
statefulset.apps/web configured
[root@node22 statefulset]# kubectl get pod
No resources found in default namespace.
[root@node22 statefulset]# kubectl delete -f statefulset.yaml
statefulset.apps "web" deleted

##PV和PVC的设计，使得StatefulSet对存储状态的管理成为了可能：


[root@node22 statefulset]# vim statefulset.yaml
apiVersion: apps/v1
kind: StatefulSet
metadata:
 name: web
spec:
 serviceName: "nginx-svc"
 replicas: 3
 selector:
  matchLabels:
   app: nginx
 template:
  metadata:
   labels:
    app: nginx
  spec:
   containers:
   - name: nginx
     image: nginx
     volumeMounts:
       - name: www
         mountPath: /usr/share/nginx/html
 volumeClaimTemplates:
  - metadata:
     name: www
    spec:
     storageClassName: nfs-client
     accessModes:
     - ReadWriteOnce
     resources:
      requests:
       storage: 1Gi
[root@node22 statefulset]# kubectl get pod
NAME    READY   STATUS    RESTARTS   AGE
web-0   0/1     Pending   0          16s
（此处是因为storageClassName: nfs-client错误，讲nfs中的class.yaml文件改为如下
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: nfs-client
provisioner: k8s-sigs.io/nfs-subdir-external-provisioner
parameters:
  archiveOnDelete: "false"
）
[root@node22 statefulset]# kubectl get pod
NAME    READY   STATUS    RESTARTS   AGE
web-0   1/1     Running   0          3m10s
web-1   1/1     Running   0          3m8s
web-2   1/1     Running   0          3m3s
[root@node22 statefulset]# kubectl get pvc
NAME        STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS   AGE
www-web-0   Bound    pvc-1cbb7bd9-1fe0-472d-8068-6a7a81fc3322   1Gi        RWO            nfs-client     9m30s
www-web-1   Bound    pvc-7be7b00f-8a40-447f-92f1-4064f8466629   1Gi        RWO            nfs-client     3m28s
www-web-2   Bound    pvc-3186a28f-c878-437b-8a03-1e4166ac0cbf   1Gi        RWO            nfs-client     3m23s
[root@node22 statefulset]# kubectl get pv
NAME                                       CAPACITY   ACCESS MODES   RECLAIM POLICY   STATUS   CLAIM               STORAGECLASS   REASON   AGE
pvc-1cbb7bd9-1fe0-472d-8068-6a7a81fc3322   1Gi        RWO            Delete           Bound    default/www-web-0   nfs-client              3m44s
pvc-3186a28f-c878-437b-8a03-1e4166ac0cbf   1Gi        RWO            Delete           Bound    default/www-web-2   nfs-client              3m29s
pvc-7be7b00f-8a40-447f-92f1-4064f8466629   1Gi        RWO            Delete           Bound    default/www-web-1   nfs-client              3m34s

Pod的创建也是严格按照编号顺序进行的。比如在web-0进入到running状态，并且Conditions为Ready之前，web-1一直会处于pending状态。

StatefulSet还会为每一个Pod分配并创建一个同样编号的PVC。这样，kubernetes就可以通过 Persistent Volume机制为这个PVC绑定对应的PV，从而保证每一个Pod都拥有一个独立的Volume。

测试：


[root@node11 nfsdata]# ll
total 4
drwxrwxrwx 2 root root  6 Aug 29 17:09 default-www-web-0-pvc-1cbb7bd9-1fe0-472d-8068-6a7a81fc3322
drwxrwxrwx 2 root root  6 Aug 29 17:09 default-www-web-1-pvc-7be7b00f-8a40-447f-92f1-4064f8466629
drwxrwxrwx 2 root root  6 Aug 29 17:09 default-www-web-2-pvc-3186a28f-c878-437b-8a03-1e4166ac0cbf
-rw-r--r-- 1 root root 15 Aug 28 20:48 index.html
drwxr-xr-x 2 root root  6 Aug 28 21:50 pv1
drwxr-xr-x 2 root root  6 Aug 28 21:50 pv2
drwxr-xr-x 2 root root  6 Aug 28 21:18 pv3
[root@node11 nfsdata]# cd default-www-web-0-pvc-1cbb7bd9-1fe0-472d-8068-6a7a81fc3322
[root@node11 default-www-web-0-pvc-1cbb7bd9-1fe0-472d-8068-6a7a81fc3322]# echo web-0 > index.html
[root@node11 default-www-web-0-pvc-1cbb7bd9-1fe0-472d-8068-6a7a81fc3322]# cd ..
[root@node11 nfsdata]# cd default-www-web-1-pvc-7be7b00f-8a40-447f-92f1-4064f8466629
[root@node11 default-www-web-1-pvc-7be7b00f-8a40-447f-92f1-4064f8466629]# echo web-1 > index.html
[root@node11 default-www-web-1-pvc-7be7b00f-8a40-447f-92f1-4064f8466629]# cd ..
[root@node11 nfsdata]# cd default-www-web-2-pvc-3186a28f-c878-437b-8a03-1e4166ac0cbf
[root@node11 default-www-web-2-pvc-3186a28f-c878-437b-8a03-1e4166ac0cbf]# echo web-2 > index.html
[root@node11 default-www-web-2-pvc-3186a28f-c878-437b-8a03-1e4166ac0cbf]# cd ..
[root@node22 statefulset]# kubectl run demo --image=busyboxplus -it --rm  进入容器内访问
If you don't see a command prompt, try pressing enter.
/ # curl web-0.nginx-svc
web-0
/ # curl web-1.nginx-svc
web-1
/ # curl web-2.nginx-svc
web-2
##回收pod并重新创建后，访问对应的pod可得到原来对应挂载卷的内容
[root@node22 statefulset]# kubectl delete -f  statefulset.yaml
statefulset.apps "web" deleted
[root@node22 statefulset]# kubectl delete pvc --all
persistentvolumeclaim "www-web-0" deleted
persistentvolumeclaim "www-web-1" deleted
persistentvolumeclaim "www-web-2" deleted
[root@node22 statefulset]# kubectl get pv
No resources found
[root@node22 statefulset]# kubectl get pod
No resources found in default namespace.

7).使用statefullset部署mysql主从集群


[root@node22 statefulset]# mkdir mysql
[root@node22 statefulset]# cd mysql/
[root@node22 mysql]# vim config.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: mysql
  labels:
    app: mysql
    app.kubernetes.io/name: mysql
data:
  primary.cnf: |
    # 仅在主服务器上应用此配置
    [mysqld]
    log-bin
  replica.cnf: |
    # 仅在副本服务器上应用此配置
    [mysqld]
    super-read-only
[root@node22 mysql]# kubectl apply -f config.yaml
configmap/mysql created
[root@node22 mysql]# kubectl get cm
NAME               DATA   AGE
cm1-config         2      38h
kube-root-ca.crt   1      4d20h
my-config          2      38h
my-config-2        1      38h
my-config-3        2      38h
mysql              2      14s
nginxconf          1      38h
[root@node22 mysql]# kubectl delete cm my-config
configmap "my-config" deleted
[root@node22 mysql]# kubectl delete cm my-config-2
configmap "my-config-2" deleted
[root@node22 mysql]# kubectl delete cm my-config-3
configmap "my-config-3" deleted
[root@node22 mysql]# kubectl get cm
NAME               DATA   AGE
cm1-config         2      38h
kube-root-ca.crt   1      4d20h
mysql              2      41s
nginxconf          1      38h

创建两个svc：
[root@node22 mysql]# vim svc.yaml
apiVersion: v1
kind: Service
metadata:
  name: mysql
  labels:
    app: mysql
    app.kubernetes.io/name: mysql
spec:
  ports:
  - name: mysql
    port: 3306
  clusterIP: None
  selector:
    app: mysql
---
# 用于连接到任一 MySQL 实例执行读操作的客户端服务
# 对于写操作，你必须连接到主服务器：mysql-0.mysql
apiVersion: v1
kind: Service
metadata:
  name: mysql-read
  labels:
    app: mysql
    app.kubernetes.io/name: mysql
    readonly: "true"
spec:
  ports:
  - name: mysql
    port: 3306
  selector:
    app: mysql
[root@node22 mysql]# kubectl apply -f svc.yaml
service/mysql created
service/mysql-read created
[root@node22 mysql]# kubectl delete svc nginx-svc
service "nginx-svc" deleted
[root@node22 mysql]# kubectl get svc
NAME         TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)    AGE
kubernetes   ClusterIP   10.96.0.1       <none>        443/TCP    4d20h
mysql        ClusterIP   None            <none>        3306/TCP   17s
mysql-read   ClusterIP   10.106.229.89   <none>        3306/TCP   17s

创建statehulset控制器：
[root@node22 mysql]# vim mysql.yaml
[root@node22 mysql]# kubectl apply -f mysql.yaml
statefulset.apps/mysql created
[root@node22 mysql]# kubectl get pod
NAME      READY   STATUS    RESTARTS      AGE
mysql-0   1/1     Running   1 (64s ago)   9m56s
[root@node22 mysql]# kubectl logs mysql-0 init-mysql
++ hostname
+ [[ mysql-0 =~ -([0-9]+)$ ]]
+ ordinal=0
+ echo '[mysqld]'
+ echo server-id=100
+ [[ 0 -eq 0 ]]
+ cp /mnt/config-map/primary.cnf /mnt/conf.d/

上传镜像：
[root@node11 ~]#  docker load -i mysql-xtrabackup.tar
[root@node11 ~]# docker push reg.westos.org/library/mysql:5.7
[root@node11 ~]# docker push  reg.westos.org/library/xtrabackup:1.0

[root@node22 mysql]# kubectl run demo --image=mysql:5.7 -it bash
If you don't see a command prompt, try pressing enter.
root@demo:/#  mysql -h mysql-0.mysql

四、kubernetes调度

• 调度器通过 kubernetes 的 watch 机制来发现集群中新创建且尚未被调度到 Node

上的 Pod。调度器会将发现的每一个未调度的 Pod 调度到一个合适的 Node 上来运

行。

• kube-scheduler 是 Kubernetes 集群的默认调度器，并且是集群控制面的一部分。

如果你真的希望或者有这方面的需求，kube-scheduler 在设计上是允许你自己写一

个调度组件并替换原有的 kube-scheduler。

• 在做调度决定时需要考虑的因素包括：单独和整体的资源请求、硬件/软件/策略限

制、亲和以及反亲和要求、数据局域性、负载间的干扰等等。

• 默认策略可以参考：https://kubernetes.io/zh/docs/concepts/scheduling/kube[1]

scheduler/

• 调度框架：https://kubernetes.io/zh/docs/concepts/configuration/scheduling[1]

framework/

• nodeName 是节点选择约束的最简单方法，但一般不推荐。如果 nodeName 在

PodSpec 中指定了，则它优先于其他的节点选择方法。

使用 nodeName 来选择节点的一些限制：

• 如果指定的节点不存在。

• 如果指定的节点没有资源来容纳 pod，则pod 调度失败。

• 云环境中的节点名称并非总是可预测或稳定的。

示例：


[root@node22 ~]# cd yaml/
[root@node22 yaml]# vim pod.yaml
apiVersion: v1
kind: Pod
metadata:
  name: demo
  namespace: default
  labels:
    app: nginx
spec:
  containers:
  - name: nginx
    image: nginx
  nodeName: node44
[root@node22 yaml]# kubectl apply -f pod.yaml
pod/demo created
[root@node22 yaml]# kubectl get pod -o wide
NAME   READY   STATUS              RESTARTS   AGE   IP       NODE     NOMINATED NODE   READINESS GATES
demo   0/1     ContainerCreating   0          15s   <none>   node44   <none>           <none>
虽然次方法使用简单，但节点的不稳定性会影响其使用。
[root@node22 yaml]# kubectl delete -f pod.yaml
pod "demo" deleted

• nodeSelector 是节点选择约束的最简单推荐形式。
• 给选择的节点添加标签：
• kubectl label nodes server2 disktype=ssd
• 添加 nodeSelector 字段到 pod 配置中：
[root@node22 yaml]# vim pod.yaml
apiVersion: v1
kind: Pod
metadata:
  name: demo
  namespace: default
  labels:
    app: nginx
spec:
  containers:
  - name: nginx
    image: nginx
  #nodeName: no
  nodeSelector:
    disktype: ssd
[root@node22 yaml]# kubectl apply -f pod.yaml
pod/demo created
[root@node22 yaml]# kubectl get pod -o wide
NAME   READY   STATUS    RESTARTS   AGE   IP               NODE     NOMINATED NODE   READINESS GATES
demo   1/1     Running   0          9s    10.244.144.110   node33   <none>           <none>
[root@node22 yaml]# kubectl delete -f pod.yaml
pod "demo" deleted

亲和与反亲和 ：

• nodeSelector 提供了一种非常简单的方法来将 pod 约束到具有特定标签的节

点上。亲和/反亲和功能极大地扩展了你可以表达约束的类型。

• 你可以发现规则是“软”/“偏好”，而不是硬性要求，因此，如果调度器无

法满足该要求，仍然调度该 pod

• 你可以使用节点上的 pod 的标签来约束，而不是使用节点本身的标签，来允

许哪些 pod 可以或者不可以被放置在一起。

• 节点亲和

• requiredDuringSchedulingIgnoredDuringExecution

必须满足

• preferredDuringSchedulingIgnoredDuringExecution

倾向满足

• IgnoreDuringExecution 表示如果在Pod运行期间Node的标签发生变化，导致

亲和性策略不能满足，则继续运行当前的Pod。

• 参考：https://kubernetes.io/zh/docs/concepts/configuration/assign-pod[1]

node/

节点亲和性pod示例：


[root@node22 ~]# mkdir node
[root@node22 ~]# cd node/
[root@node22 node]# vim pod.yaml
apiVersion: v1
kind: Pod
metadata:
   name: node-affinity
spec:
  containers:
  - name: nginx
    image: nginx
  affinity:
    nodeAffinity:
      requiredDuringSchedulingIgnoredDuringExecution:
           nodeSelectorTerms:
           - matchExpressions:
             - key: disktype
               operator: In
               values:
                 - ssd
                 - sata
[root@node22 node]# kubectl apply -f pod.yaml
pod/node-affinity created
[root@node22 node]# kubectl get pod -o wide
NAME            READY   STATUS    RESTARTS   AGE   IP               NODE     NOMINATED NODE   READINESS GATES
node-affinity   1/1     Running   0          14s   10.244.144.111   node33   <none>           <none>
[root@node22 node]# kubectl get node --show-labels
NAME     STATUS   ROLES                  AGE   VERSION    LABELS
node22   Ready    control-plane,master   9d    v1.23.10   beta.kubernetes.io/arch=amd64,beta.kubernetes.io/os=linux,kubernetes.io/arch=amd64,kubernetes.io/hostname=node22,kubernetes.io/os=linux,node-role.kubernetes.io/control-plane=,node-role.kubernetes.io/master=,node.kubernetes.io/exclude-from-external-load-balancers=
node33   Ready    <none>                 9d    v1.23.10   beta.kubernetes.io/arch=amd64,beta.kubernetes.io/os=linux,disktype=ssd,kubernetes.io/arch=amd64,kubernetes.io/hostname=node33,kubernetes.io/os=linux
node44   Ready    <none>                 9d    v1.23.10   beta.kubernetes.io/arch=amd64,beta.kubernetes.io/os=linux,disktype=ssd,ingress=nginx,kubernetes.io/arch=amd64,kubernetes.io/hostname=node44,kubernetes.io/os=linux
[root@node22 node]# kubectl delete -f pod.yaml
pod "node-affinity" deleted

加了倾向性后就会倾向于条件，如果不满足条件，不会影响调度，只要满足必要条件就好
[root@node22 node]# vim pod.yaml
apiVersion: v1
kind: Pod
metadata:
  name: node-affinity
spec:
  containers:
  - name: nginx
    image: nginx
  affinity:
    nodeAffinity:
      requiredDuringSchedulingIgnoredDuringExecution:
           nodeSelectorTerms:
           - matchExpressions:
             - key: disktype
               operator: In
               values:
                 - ssd
                 - sata
                 - fc
      preferredDuringSchedulingIgnoredDuringExecution:
      - weight: 1
        preference:
          matchExpressions:
          - key: ingress
            operator: In
            values:
            - nginx
[root@node22 node]# kubectl apply  -f pod.yaml
pod/node-affinity created
[root@node22 node]# kubectl get pod -o wide  调度到了符合条件的node44
NAME            READY   STATUS    RESTARTS   AGE   IP               NODE     NOMINATED NODE   READINESS GATES
node-affinity   1/1     Running   0          21s   10.244.214.140   node44   <none>           <none>

1).nodeaffinity还支持多种规则匹配条件的配置：

In：label的值在列表内

NotIn：label的值不在列表内

Gt：label的值大于设置的值，不支持Pod亲和性

Lt：label的值小于设置的值，不支持pod亲和性

Exists：设置的label存在

DoesNotExist：设置的label不存在

2).pod亲和性和反亲和性

podAffinity主要解决POD可以和哪些POD部署在同一个拓扑域中的问题（拓扑域用主机标签实现，可以是单个主机，也可以是多个主机组成的cluster、zone等）

podAntiAffinity主要解决POD不能和哪些POD部署在同一个拓扑域中的问题；它们处理的是Kubernetes集群内部POD和POD之间的关系

Pod间亲和与反亲和在与更高级别的集合（例如ReplicaSets、StatefulSets、Deployments等）一起使用时，它们可能更加有用，可以轻松配置一组应位于相同定义拓扑（例如，节点）中的工作负载

pod亲和性：


[root@node22 node]# vim pod2.yaml
apiVersion: v1
kind: Pod
metadata:
  name: myapp
  labels:
    app: myapp
spec:
  containers:
  - name: myapp
    image: myapp:v1
  hostNetwork: true
  nodeName: node33
[root@node22 node]# kubectl apply -f pod2.yaml
pod/myapp created
[root@node22 node]# kubectl get pod
NAME    READY   STATUS    RESTARTS     AGE
myapp   0/1     Error     1 (8s ago)   11s
nginx   1/1     Running   0            3m25s
[root@node22 node]# kubectl get pod -o wide
NAME    READY   STATUS    RESTARTS      AGE    IP             NODE     NOMINATED NODE   READINESS GATES
myapp   1/1     Running   3 (31s ago)   53s    192.168.0.33   node33   <none>           <none>
nginx   1/1     Running   0             4m7s   192.168.0.33   node33   <none>           <none>

[root@node22 node]# vim pod4.yaml
apiVersion: v1
kind: Pod
metadata:
  name: mysql
  labels:
    app: mysql
spec:
  containers:
  - name: mysql
    image: mysql:5.7
    env:
     - name: "MYSQL_ROOT_PASSWORD"
       value: "westos"
  affinity:
    podAntiAffinity:
      requiredDuringSchedulingIgnoredDuringExecution:
      - labelSelector:
          matchExpressions:
          - key: app
            operator: In
            values:
            - nginx
        topologyKey: kubernetes.io/hostname
[root@node22 node]# kubectl apply -f pod4.yaml
pod/mysql created
[root@node22 node]# kubectl get pod -o wide
NAME    READY   STATUS    RESTARTS      AGE    IP             NODE     NOMINATED NODE   READINESS GATES
myapp   1/1     Running   3 (31s ago)   53s    192.168.0.33   node33   <none>           <none>
nginx   1/1     Running   0             4m7s   192.168.0.33   node33   <none>           <none>

pod反亲和性：


[root@node22 node]# vim pod3.yaml
apiVersion: v1
kind: Pod
metadata:
  name: myapp
  labels:
    app: myapp
spec:
  containers:
  - name: myapp
    image: myapp:v1
  hostNetwork: true
  affinity:
    podAntiAffinity:
      requiredDuringSchedulingIgnoredDuringExecution:
      - labelSelector:
          matchExpressions:
          - key: app
            operator: In
            values:
            - nginx
        topologyKey: "kubernetes.io/hostname"
[root@node22 node]# kubectl delete -f pod3.yaml
pod "myapp" deleted
[root@node22 node]# kubectl apply -f pod3.yaml
pod/myapp created
[root@node22 node]# kubectl get pod -o wide
NAME    READY   STATUS    RESTARTS   AGE     IP             NODE     NOMINATED NODE   READINESS GATES
myapp   1/1     Running   0          12s     192.168.0.44   node44   <none>           <none>
nginx   1/1     Running   0          7m57s   192.168.0.33   node33   <none>           <none>

3).Taints污点

https://kubernetes.io/zh/docs/concepts/scheduling-eviction/taint-and-toleration/

NodeAffinity节点亲和性，是Pod上定义的一种属性，使Pod能够按我们的要求调度到某个Node上，而Taints则恰恰相反，它可以让Node拒绝运行Pod，甚至驱逐Pod

Taints(污点)是Node的一个属性，设置了Taints后，Kubernetes是不会将Pod调度到这个Node上的，于是Kubernetes就给Pod设置了个属性Tolerations(容忍)，只要Pod能够容忍Node上的污点，那么Kubernetes就会忽略Node上的污点，就能够(不是必须)把Pod调度过去

可以使用命令 kubectl taint 给节点增加一个 taint：

kubectl taint nodes node1 key=value:NoSchedule //创建

kubectl describe nodes server1 |grep Taints //查询

kubectl taint nodes node1 key:NoSchedule- //删除

其中[effect] 可取值： [ NoSchedule | PreferNoSchedule | NoExecute ]

• NoSchedule：POD 不会被调度到标记为 taints 节点。

• PreferNoSchedule：NoSchedule 的软策略版本。

• NoExecute：该选项意味着一旦 Taint 生效，如该节点内正在运行的 POD 没有对应

Tolerate 设置，会直接被逐出。

##集群节点的master不参与调度是因为其上有Taints，而worker节点没有此污点


[root@node22 node]# kubectl describe nodes node22 | grep Tain
Taints:             node-role.kubernetes.io/master:NoSchedule
[root@node22 node]# kubectl describe nodes node33 | grep Tain
Taints:             <none>
[root@node22 node]# kubectl describe nodes node44 | grep Tain
Taints:             <none>
[root@node22 node]# kubectl create deployment demo --image=myapp:v1 --replicas=3
[root@node22 node]# kubectl get pod -o wide
NAME                    READY   STATUS    RESTARTS   AGE   IP               NODE     NOMINATED NODE   READINESS GATES
demo-7c4d6f8c46-856fc   1/1     Running   0          19s   10.244.144.113   node33   <none>           <none>
demo-7c4d6f8c46-ss2nw   1/1     Running   0          19s   10.244.144.112   node33   <none>           <none>
demo-7c4d6f8c46-wljn8   1/1     Running   0          19s   10.244.214.143   node44   <none>           <none>

给node33加NoSchedule污点：

##为集群中的node33主机打上污点后，后续pod都会被调度至没有污点的node44主机上


[root@node22 node]# kubectl delete pod --all   删除不用的pod
pod "mysql" deleted
pod "nginx" deleted
[root@node22 node]# kubectl taint node node33 k1=v1:NoSchedule
node/node33 tainted
[root@node22 node]# kubectl describe nodes node33 | grep Tain
Taints:             k1=v1:NoSchedule
[root@node22 node]# kubectl scale deployment demo --replicas=6 把副本数拉升为6个
deployment.apps/demo scaled
[root@node22 node]# kubectl get pod -o wide
NAME                    READY   STATUS    RESTARTS   AGE     IP               NODE     NOMINATED NODE   READINESS GATES
demo-7c4d6f8c46-856fc   1/1     Running   0          4m50s   10.244.144.113   node33   <none>           <none>
demo-7c4d6f8c46-8qsng   1/1     Running   0          44s     10.244.214.145   node44   <none>           <none>
demo-7c4d6f8c46-9jmkc   1/1     Running   0          44s     10.244.214.144   node44   <none>           <none>
demo-7c4d6f8c46-ss2nw   1/1     Running   0          4m50s   10.244.144.112   node44   <none>           <none>
demo-7c4d6f8c46-vlfws   1/1     Running   0          44s     10.244.214.146   node44   <none>           <none>
demo-7c4d6f8c46-wljn8   1/1     Running   0          4m50s   10.244.214.143   node44   <none>           <none>

给node44加NoExecute污点：

##给node44节点主机也打上污点后，原来运行在其上面的pod会被驱离


[root@node22 node]# kubectl taint node node44 k1=v1:NoExecute
node/node44 tainted
[root@node22 node]# kubectl describe nodes node44 | grep Tain
Taints:             k1=v1:NoExecute
[root@node22 node]# kubectl get pod -o wide
NAME                    READY   STATUS    RESTARTS   AGE     IP               NODE     NOMINATED NODE   READINESS GATES
demo-7c4d6f8c46-5gw59   0/1     Pending   0          22s     <none>           <none>   <none>           <none>
demo-7c4d6f8c46-5ww9h   0/1     Pending   0          20s     <none>           <none>   <none>           <none>
demo-7c4d6f8c46-7xmsw   0/1     Pending   0          20s     <none>           <none>   <none>           <none>
demo-7c4d6f8c46-856fc   1/1     Running   0          7m28s   10.244.144.113   node33   <none>           <none>
demo-7c4d6f8c46-rthws   0/1     Pending   0          20s     <none>           <none>   <none>           <none>
demo-7c4d6f8c46-ss2nw   1/1     Running   0          7m28s   10.244.144.112   node33   <none>           <none>

##在pod清单文件中配置污点容忍后，node44主机其上又可以重新运行pod

[root@node22 node]# vim myapp.yaml 容忍NoSchedule污点：

[root@node22 node]# kubectl apply -f myapp.yaml

Warning: resource deployments/demo is missing the kubectl.kubernetes.io/last-applied-configuration annotation which is required by kubectl apply. kubectl apply should only be used on resources created declaratively by either kubectl create --save-config or kubectl apply. The missing annotation will be patched automatically.

deployment.apps/demo configured

[root@node22 node]# kubectl get pod -o wide

NAME                    READY   STATUS    RESTARTS   AGE   IP               NODE     NOMINATED NODE   READINESS GATES

demo-7df9764968-2hw59   1/1     Running   0          7s    10.244.144.118 node33

demo-7df9764968-8cfdf   1/1     Running   0          23s   10.244.144.116   node33

demo-7df9764968-8rbg8   1/1     Running   0          7s    10.244.144.117   node33

demo-7df9764968-hlxcj   1/1     Running   0          23s   10.244.144.114   node33

demo-7df9764968-jthwv   1/1     Running   0          6s    10.244.144.119   node33

demo-7df9764968-mzqn9   1/1     Running   0          23s   10.244.144.115   node33

[root@node22 node]# vim myapp.yaml 容忍所有污点

[root@node22 node]# kubectl apply -f myapp.yaml

deployment.apps/demo created

[root@node22 node]# kubectl get pod -o wide

NAME                   READY   STATUS              RESTARTS   AGE   IP               NODE     NOMINATED NODE   READINESS GATES

demo-5f7ffd8d99-hsvt5   1/1     Running             0          7s    10.244.214.147   node44

demo-5f7ffd8d99-jbnpt   1/1     Running             0          7s    10.244.214.148   node44

demo-5f7ffd8d99-mzbhh   1/1     Running             0          7s    10.244.144.121   node33

demo-5f7ffd8d99-nv746   0/1     ContainerCreating   0          7s               node22

demo-5f7ffd8d99-wq2pb   0/1     ContainerCreating   0          7s               node22

demo-5f7ffd8d99-zhggq   1/1     Running             0          7s   10.244.144.120   node33

tolerations中定义的key、value、effect，要与node上设置的taint保持一直：

• 如果 operator 是 Exists ，value可以省略。

• 如果 operator 是 Equal ，则key与value之间的关系必须相等。

• 如果不指定operator属性，则默认值为Equal。

还有两个特殊值：

• 当不指定key，再配合Exists 就能匹配所有的key与value ，可以容忍所有污点。

• 当不指定effect ，则匹配所有的effect。


[root@node22 node]# kubectl delete -f myapp.yaml
deployment.apps "demo" deleted
[root@node22 node]# kubectl taint node node33 k1-
node/node33 untainted
[root@node22 node]# kubectl taint node node44 k1-
node/node44 untainted
[root@node22 node]# kubectl describe nodes | grep Tain
Taints:             node-role.kubernetes.io/master:NoSchedule
Taints:             <none>
Taints:             <none>

4).影响Pod调度的指令还有：cordon、drain、delete，后期创建的pod都不会被调度到

该节点上，但操作的暴力程度不一样。

cordon 停止调度：

• 影响最小，只会将node调为SchedulingDisabled，新创建pod，不会被调度到该节点，节

点原有pod不受影响，仍正常对外提供服务。


[root@node22 node]# kubectl get node
NAME     STATUS   ROLES                  AGE   VERSION
node22   Ready    control-plane,master   9d    v1.23.10
node33   Ready    <none>                 9d    v1.23.10
node44   Ready    <none>                 9d    v1.23.10
[root@node22 node]# kubectl cordon node33
node/node33 cordoned
[root@node22 node]# kubectl get node
NAME     STATUS                     ROLES                  AGE   VERSION
node22   Ready                      control-plane,master   9d    v1.23.10
node33   Ready,SchedulingDisabled   <none>                 9d    v1.23.10
node44   Ready                      <none>                 9d    v1.23.10
[root@node22 node]# kubectl uncordon node33  取消禁用
node/node33 uncordoned

5).drain 驱逐节点：

• 首先驱逐node上的pod，在其他节点重新创建，然后将节点调为SchedulingDisabled。


[root@node22 node]# kubectl create  deployment  demo --image=nginx --replicas=3
deployment.apps/demo created
[root@node22 node]# kubectl get pod -o wide
NAME                    READY   STATUS    RESTARTS   AGE   IP               NODE     NOMINATED NODE   READINESS GATES
demo-6c54f77c95-78mhw   1/1     Running   0          7s    10.244.214.151   node44   <none>           <none>
demo-6c54f77c95-c9jp7   1/1     Running   0          7s    10.244.144.123   node33   <none>           <none>
demo-6c54f77c95-j8rtj   1/1     Running   0          7s    10.244.144.122   node33   <none>           <none>
root@node22 node]# kubectl drain node44 --ignore-daemonsets
node/node44 already cordoned
WARNING: ignoring DaemonSet-managed Pods: kube-system/calico-node-2tgjc, kube-system/kube-proxy-zh89l, metallb-system/speaker-4hb2q
evicting pod metallb-system/controller-5c97f5f498-zkkww
evicting pod default/demo-6c54f77c95-78mhw
evicting pod ingress-nginx/ingress-nginx-controller-5bbfbbb9c7-d82hw
pod/controller-5c97f5f498-zkkww evicted
pod/demo-6c54f77c95-78mhw evicted
pod/ingress-nginx-controller-5bbfbbb9c7-d82hw evicted
node/node44 drained
[root@node22 node]# kubectl get pod -o wide
NAME                    READY   STATUS    RESTARTS   AGE   IP               NODE     NOMINATED NODE   READINESS GATES
demo-6c54f77c95-bl47m   1/1     Running   0          17s   10.244.144.124   node33   <none>           <none>
demo-6c54f77c95-c9jp7   1/1     Running   0          79s   10.244.144.123   node33   <none>           <none>
demo-6c54f77c95-j8rtj   1/1     Running   0          79s   10.244.144.122   node33   <none>           <none>
[root@node22 node]# kubectl get node
NAME     STATUS                     ROLES                  AGE   VERSION
node22   Ready                      control-plane,master   9d    v1.23.10
node33   Ready                      <none>                 9d    v1.23.10
node44   Ready,SchedulingDisabled   <none>                 9d    v1.23.10

6).delete 删除节点

• 最暴力的一个，首先驱逐node上的pod，在其他节点重新创建，然后，从master节点删除

该node，master失去对其控制，如要恢复调度，需进入node节点，重启kubelet服务


[root@node22 node]# kubectl delete nodes node44
node "node44" deleted
[root@node22 node]# kubectl get node
NAME     STATUS   ROLES                  AGE   VERSION
node22   Ready    control-plane,master   9d    v1.23.10
node33   Ready    <none>                 9d    v1.23.10
[root@node44 ~]#  systemctl restart  kubelet重启节点上的kubelete基于node的自注册功能,恢复使用
[root@node22 node]# kubectl get node
NAME     STATUS   ROLES                  AGE   VERSION
node22   Ready    control-plane,master   9d    v1.23.10
node33   Ready    <none>                 9d    v1.23.10
node44   Ready    <none>                 31s   v1.23.10

五、kubernetes访问控制

1.kubernetes API 访问控制

Authentication（认证）

• 认证方式现共有8种，可以启用一种或多种认证方式，只要有一种认证方式通过，就不再

进行其它方式的认证。通常启用X509 Client Certs和Service Accout Tokens两种认证方式。

• Kubernetes集群有两类用户：由Kubernetes管理的Service Accounts （服务账户）和

（Users Accounts）普通账户。k8s中账号的概念不是我们理解的账号，它并不真的存在，

它只是形式上存在。

Authorization（授权）

• 必须经过认证阶段，才到授权请求，根据所有授权策略匹配请求资源属性，决定允许或拒

绝请求。授权方式现共有6种，AlwaysDeny、AlwaysAllow、ABAC、RBAC、Webhook、

Node。默认集群强制开启RBAC。

Admission Control（准入控制）

• 用于拦截请求的一种方式，运行在认证、授权之后，是权限认证链上的最后一环，对请求

API资源对象进行修改和校验。

访问k8s的API Server的客户端主要分为两类：

• kubectl ：用户家目录中的 .kube/config 里面保存了客户端访问API Server的密钥相关信息，

这样当用kubectl访问k8s时，它就会自动读取该配置文件，向API Server发起认证，然后

完成操作请求。

• pod：Pod中的进程需要访问API Server，如果是人去访问或编写的脚本去访问，这类访问

使用的账号为：UserAccount；而Pod自身去连接API Server时，使用的账号是：

ServiceAccount，生产中后者使用居多。

kubectl向apiserver发起的命令,采用的是http方式,其实就是对URL发起增删改查的操作。

• kubectl proxy --port=8888 &

• curl http://localhost:8888/api/v1/namespaces/default

• curl http://localhost:8888/apis/apps/v1/namespaces/default/deployments

以上两种api的区别是：

• api它是一个特殊链接,只有在核心v1群组中的对象才能使用。

• apis 它是一般API访问的入口固定格式名。kubernetes访问控制

UserAccount与serviceaccount：

• 用户账户是针对人而言的。服务账户是针对运行在 pod 中的进程而言的。

• 用户账户是全局性的。其名称在集群各 namespace 中都是全局唯一的，未来的用户资源不

会做 namespace 隔离，服务账户是 namespace 隔离的。

• 通常情况下，集群的用户账户可能会从企业数据库进行同步，其创建需要特殊权限，并且涉

及到复杂的业务流程。服务账户创建的目的是为了更轻量，允许集群用户为了具体的任务

创建服务账户 ( 即权限最小化原则 )。

创建服务账号（serviceaccount）


[root@node22 ~]# kubectl delete pvc --all  删除多余pvc
persistentvolumeclaim "data-mysql-0" deleted
[root@node22 ~]# kubectl create sa admin  创建admin账号（服务）
serviceaccount/admin created
[root@node22 ~]# kubectl get sa 查看sa账号
NAME      SECRETS   AGE
admin     1         52s
default   1         9d
[root@node22 ~]# kubectl describe sa admin此时k8s为用户自动生成认证信息，但没有授权
Name:                admin            查看sa信息
Namespace:           default
Labels:              <none>
Annotations:         <none>
Image pull secrets:  <none>
Mountable secrets:   admin-token-jbwqn
Tokens:              admin-token-jbwqn
Events:              <none>
[root@node22 ~]# kubectl run demo --image=nginx  创建容器
pod/demo created
[root@node22 ~]# kubectl get pod demo -o yaml | grep default  默认使用default账号
  namespace: default
  schedulerName: default-scheduler
  serviceAccount: default
  serviceAccountName: default
      defaultMode: 420
[root@node22 ~]# kubectl delete pod demo
pod "demo" deleted

添加secrets到serviceaccount中：


[root@node22 sa]# kubectl patch serviceaccount admin -p '{"imagePullSecrets": [{"name": "myregistrykey"}]}'
serviceaccount/admin patched
[root@node22 sa]# kubectl describe sa admin
Name:                admin
Namespace:           default
Labels:              <none>
Annotations:         <none>
Image pull secrets:  myregistrykey
Mountable secrets:   admin-token-jbwqn
Tokens:              admin-token-jbwqn
Events:              <none>

把serviceaccount和pod绑定起来：


[root@node22 ~]# mkdir sa
[root@node22 ~]# cd sa
[root@node22 sa]# vim pod.yaml  定义一个admin用户
apiVersion: v1
kind: Pod
metadata:
  name: myapp
  labels:
    app: myapp
spec:
  containers:
  - name: myapp
    image: reg.westos.org/westos/game2048
    ports:
    - name: http
      containerPort: 80
  serviceAccountName: admin
[root@node22 sa]# kubectl apply -f pod.yaml
pod/myapp created
[root@node22 sa]# kubectl get pod 拉取私有仓库里的镜像需要认证
NAME                    READY   STATUS             RESTARTS   AGE
demo-6c54f77c95-bl47m   1/1     Running            0          101m
demo-6c54f77c95-c9jp7   1/1     Running            0          102m
demo-6c54f77c95-j8rtj   1/1     Running            0          102m
myapp                   0/1     ImagePullBackOff   0          18s
[root@node22 sa]# kubectl delete deployments.apps  demo
deployment.apps "demo" deleted
[root@node22 sa]# kubectl delete pod myapp
pod "myapp" deleted

做完上面的添加secrets到serviceaccount中后就可拉取


[root@node22 sa]# kubectl apply -f  pod.yaml
pod/myapp created
[root@node22 sa]# kubectl get pod
NAME    READY   STATUS    RESTARTS   AGE
myapp   1/1     Running   0          18s
[root@node22 sa]# kubectl delete pod myapp
pod "myapp" deleted

创建用户账号（UserAccount）


[root@node22 sa]# cd /etc/kubernetes/pki/
[root@node22 pki]#  openssl genrsa -out test.key 2048  生成一个测试key
[root@node22 pki]# openssl req -new -key test.key -out test.csr -subj "/CN=test"通过私钥生成证书请求文件
[root@node22 pki]#  openssl x509 -req -in test.csr -CA ca.crt -CAkey ca.key -CAcreateserial -out test.crt -days 365    通过证书请求文件生成证书
Signature ok
subject=/CN=test
Getting CA Private Key
[root@node22 pki]# kubectl config set-credentials test --client-certificate=/etc/kubernetes/pki/test.crt --client-key=/etc/kubernetes/pki/test.key --embed-certs=true
User "test" set.
[root@node22 pki]#  kubectl config set-context test@kubernetes --cluster=kubernetes --user=test  创建用户上下文
Context "test@kubernetes" created.
[root@node22 pki]# kubectl config use-context test@kubernetes  切换到test账号
Switched to context "test@kubernetes".
[root@node22 pki]# kubectl config view  查看
apiVersion: v1
clusters:
- cluster:
    certificate-authority-data: DATA+OMITTED
    server: https://192.168.0.22:6443
  name: kubernetes
contexts:
- context:
    cluster: kubernetes
    user: kubernetes-admin
  name: kubernetes-admin@kubernetes
- context:
    cluster: kubernetes
    user: test
  name: test@kubernetes
current-context: test@kubernetes
kind: Config
preferences: {}
users:
- name: kubernetes-admin
  user:
    client-certificate-data: REDACTED
    client-key-data: REDACTED
- name: test
  user:
    client-certificate-data: REDACTED
    client-key-data: REDACTED
[root@node22 pki]# kubectl get pod权限不够
Error from server (Forbidden): pods is forbidden: User "test" cannot list resource "pods" in API group "" in the namespace "default"
此时用户通过认证，但还没有权限操作集群资源，需要继续添加授权。

RBAC（Role Based Access Control）：基于角色访问控制授权

允许管理员通过Kubernetes API动态配置授权策略，RBAC就是用户通过角色与权限进行关联；RBAC只有授权，没有拒绝授权，所以只需要定义允许该用户做什么即可；RBAC包括四种类型：Role、ClusterRole、RoleBinding、ClusterRoleBinding

RBAC的三个基本概念

Subject：被作用者，它表示k8s中的三类主体---user、group、serviceAccount

Role：角色，它其实是一组规则，定义了一组对Kubernetes API对象的操作权限

RoleBinding：定义了“被作用者”和“角色”的绑定关系

RBAC的三个基本概念：

• Subject：被作用者，它表示k8s中的三类主体， user， group， serviceAccount

• Role：角色，它其实是一组规则，定义了一组对 Kubernetes API 对象的操作权限。

• RoleBinding：定义了“被作用者”和“角色”的绑定关系。

Role 和 ClusterRole

• Role是一系列的权限的集合，Role只能授予单个namespace 中资源的访问权限。

• ClusterRole 跟 Role 类似，但是可以在集群中全局使用。

创建局部角色：


[root@node22 sa]# vim role.yaml
kind: Role
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  namespace: default
  name: myrole
rules:
- apiGroups: [""]
  resources: ["pods"]
  verbs: ["get", "watch", "list", "create", "update", "patch", "delete"]
[root@node22 sa]# kubectl config use-context kubernetes-admin@kubernetes  切换到admin
Switched to context "kubernetes-admin@kubernetes".
[root@node22 sa]# kubectl apply -f role.yaml  创建角色
role.rbac.authorization.k8s.io/myrole created
[root@node22 sa]# kubectl get role  查看角色
NAME     CREATED AT
myrole   2022-09-03T14:04:53Z

RoleBinding和ClusterRoleBinding ：

• RoleBinding是将Role中定义的权限授予给用户或用户组。它包含一个subjects

列表(users，groups ，service accounts)，并引用该Role。

• RoleBinding是对某个namespace 内授权，ClusterRoleBinding适用在集群范围

内使用。

绑定角色;


[root@node22 sa]# vim bind.yaml
kind: RoleBinding
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: test-read-pods
  namespace: default
subjects:
- kind: User
  name: test
  apiGroup: rbac.authorization.k8s.io
roleRef:
  kind: Role
  name: myrole
  apiGroup: rbac.authorization.k8s.io
[root@node22 sa]# kubectl apply -f bind.yaml
rolebinding.rbac.authorization.k8s.io/test-read-pods created
[root@node22 sa]# kubectl get rolebindings.rbac.authorization.k8s.io
NAME             ROLE          AGE
test-read-pods   Role/myrole   14s
[root@node22 sa]# kubectl config use-context test@kubernetes  切换到test用户
Switched to context "test@kubernetes".
[root@node22 sa]# kubectl get pod
No resources found in default namespace.
[root@node22 sa]# kubectl run demo --image=nginx  可以操控pod
pod/demo created

创建集群角色：


[root@node22 sa]# vim role.yaml
kind: Role
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  namespace: default
  name: myrole
rules:
- apiGroups: [""]
  resources: ["pods"]
  verbs: ["get", "watch", "list", "create", "update", "patch", "delete"]

---
kind: ClusterRole
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: myclusterrole
rules:
- apiGroups: [""]
  resources: ["pods"]
  verbs: ["get", "watch", "list", "delete", "create", "update"]
- apiGroups: ["extensions", "apps"]
  resources: ["deployments"]
  verbs: ["get", "list", "watch", "create", "update", "patch", "delete"]
[root@node22 sa]# kubectl apply -f role.yaml
role.rbac.authorization.k8s.io/myrole unchanged
clusterrole.rbac.authorization.k8s.io/myclusterrole created

创建集群角色绑定：


[root@node22 sa]# vim bind.yaml
kind: RoleBinding
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: test-read-pods
  namespace: default
subjects:
- kind: User
  name: test
  apiGroup: rbac.authorization.k8s.io
roleRef:
  kind: Role
  name: myrole
  apiGroup: rbac.authorization.k8s.io

---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: rolebind-myclusterrole
  namespace: default
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: myclusterrole
subjects:
- apiGroup: rbac.authorization.k8s.io
  kind: User
  name: test
[root@node22 sa]# kubectl apply -f bind.yaml
rolebinding.rbac.authorization.k8s.io/test-read-pods unchanged
rolebinding.rbac.authorization.k8s.io/rolebind-myclusterrole created
[root@node22 sa]# kubectl config use-context test@kubernetes  切换到test用户
Switched to context "test@kubernetes".
[root@node22 sa]# kubectl get pod
No resources found in default namespace.
[root@node22 sa]# kubectl get deployments.apps
No resources found in default namespace.
[root@node22 sa]# kubectl create deployments demo --images=nginx
error: unknown flag: --images
See 'kubectl create --help' for usage.
[root@node22 sa]# kubectl create deployments demo --image=nginx
error: unknown flag: --image
See 'kubectl create --help' for usage.
[root@node22 sa]# kubectl create deployment demo --image=nginx
deployment.apps/demo created
[root@node22 sa]# kubectl delete deployments.apps demo
deployment.apps "demo" deleted
[root@node22 sa]# kubectl get deployments.apps  -n kube-system  不能切换到其他namespace
Error from server (Forbidden): deployments.apps is forbidden: User "test" cannot list resource "deployments" in API group "apps" in the namespace "kube-system"
[root@node22 sa]# kubectl config use-context kubernetes-admin@kubernetes 切换到admin
Switched to context "kubernetes-admin@kubernetes".

创建clusterrolebinding：


[root@node22 sa]# vim bind.yaml
kind: RoleBinding
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: test-read-pods
  namespace: default
subjects:
- kind: User
  name: test
  apiGroup: rbac.authorization.k8s.io
roleRef:
  kind: Role
  name: myrole
  apiGroup: rbac.authorization.k8s.io

---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: rolebind-myclusterrole
  namespace: default
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: myclusterrole
subjects:
- apiGroup: rbac.authorization.k8s.io
  kind: User
  name: test

---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: clusterrolebinding-myclusterrole
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: myclusterrole
subjects:
- apiGroup: rbac.authorization.k8s.io
  kind: User
  name: test
[root@node22 sa]# kubectl apply -f bind.yaml   可以操作整个集群的namespace
rolebinding.rbac.authorization.k8s.io/test-read-pods unchanged
rolebinding.rbac.authorization.k8s.io/rolebind-myclusterrole unchanged
clusterrolebinding.rbac.authorization.k8s.io/clusterrolebinding-myclusterrole created

服务账户的自动化

服务账户准入控制器（Service account admission controller):

• 如果该 pod 没有 ServiceAccount 设置，将其 ServiceAccount 设为 default。

• 保证 pod 所关联的 ServiceAccount 存在，否则拒绝该 pod。

• 如果 pod 不包含 ImagePullSecrets 设置，那么将 ServiceAccount 中的

ImagePullSecrets 信息添加到 pod 中。

• 将一个包含用于 API 访问的 token 的 volume 添加到 pod 中。

• 将挂载于 /var/run/secrets/kubernetes.io/serviceaccount 的 volumeSource 添加到

pod 下的每个容器中。

Token 控制器（Token controller）

• 检测服务账户的创建，并且创建相应的 Secret 以支持 API 访问。

• 检测服务账户的删除，并且删除所有相应的服务账户 Token Secret。

• 检测 Secret 的增加，保证相应的服务账户存在，如有需要，为 Secret 增加 token。

• 检测 Secret 的删除，如有需要，从相应的服务账户中移除引用。

服务账户控制器（Service account controller）

• 服务账户管理器管理各命名空间下的服务账户，并且保证每个活跃的命名空间下存在

一个名为 “default” 的服务账户

Kubernetes 还拥有“用户组”（Group）的概念：

• ServiceAccount对应内置“用户”的名字是：

• system:serviceaccount:名字 >

• 而用户组所对应的内置名字是：

• system:serviceaccounts:名字 >

示例1：表示mynamespace中的所有ServiceAccount

subjects:

- kind: Group

apiGroup: rbac.authorization.k8s.io

示例2：表示整个系统中的所有ServiceAccount

subjects:

- kind: Group

apiGroup: rbac.authorization.k8s.io

Kubernetes 还提供了四个预先定义好的 ClusterRole 来供用户直接使用：

• cluster-amdin 管理集群

• admin 可以管理

• edit 可写

• view 只读

示例：(最佳实践)

kind: RoleBinding

apiVersion: rbac.authorization.k8s.io/v1

metadata:

subjects:

- kind: ServiceAccount

namespace: default

roleRef:

kind: ClusterRole

apiGroup: rbac.authorization.k8s.io

相关阅读:
OpenCV实战之人脸美颜美型算法
 HTML 学习笔记(七)列表
 vue 子页面通过暴露属性，实现主页面的某事件的触发
 了解操作符的那些事（二）
ABAP RFC
SystemVerilog 控制流语句
 Golang使用自定义IP请求https
使用ElementUI结合Mock完成主页的搭建
 人工智能前沿——AI技术在医疗领域的应用（二）
esxi下实现ikuai相同的两个网卡，单独路由配置
原文地址：https://blog.csdn.net/z17609273238/article/details/126936547
